Icom IC-910H Programming Manual page 16

To send PTT ID
Press PTT to send the tone. The TX PTT ID will flash continuously on the RX radio(s).
RX Radio:
Memory Ch
Field
5Tone Signaling » Form
5Tone Signaling » RX C.No
RX Code CH (under 5 Tone)
Field
Line 1 » RX Code
RX Code Setting (under 5 Tone)
Field
Compare Digit
14
Setting / Description
Set to DTMF
st
Set to 1. Points to 1
TX Radio's ID.
Setting / Description
Line 1= Enter in a " ++++7" . The plus's are place holders
which allows the RX radio to see any first 4 numbers TX'd
in 5-Tone mode. The "7" is the qualifier and tells the RX
radio to look at the 1
at the end.
Setting / Description
Sets which digits you want displayed on the RX radio
display. For example: In receiving ID 23787, if you want the
display too show the "378" part of the ID, enter in 234 (these
are the digit spaces you want displayed)
line in the RX Code CH window: the
st
4 digits. All radios involved need the 7
© June 2011 Icom America
