Programming for 5-Tone Calls with Open Mic

This procedure enables you to call a particular radio (selective call) and listen with the RX radio mic open for a
pre period of time.
The following instructions assume that frequencies, tones, and squelch are set and the radios are in PMR mode
(found in the Menu bar under Model). These instructions apply to all Icom radios with PMR capability.
TX Radio:
Memory Ch
Field
CH Mute
Switch Action » Call
5Tone Signaling » Form
5Tone Signaling » STN
TX Code CH (under 5 Tone):
Field
Line 1
Line 2, 3...
Key and Display (under Common)
Field
Key » P0-P3
Common (under Common):
Field
Auto Reset » Timer B
© June 2011 Icom America
Setting / Description
Mute options depend on radio model:
Cont (not muted)
Or (not muted)
Set to Audible
Set to EIA
st
Set to 1. Points to 1
Radio's 5 Tone code
Setting / Description
Target radio ID
5-tone for multiple target radios
Setting / Description
Assign a key (right-click Conventional field to access
menu) for the following functions:
TX Code CH Select— Enters the Code Select mode so
that you can select a target radio from the TX Code
Channel list.
TX Code CH Up—Allows you to scroll through the target
radio list and select a radio. (As an alternative, you can
also use the Up/Down keys to scroll.)
Call—Sends the 5-tone signal to the target radio.
Setting / Description
This timer sets how long mute will be open (and other reset
functions). Set to 10 sec, or as desired.
line in the TX Code CH window: target
