5Tone Tx Code Setting Window - Icom IC-910H Programming Manual

5Tone TX Code Setting Window

Field
Long Tone(Sec)
Link R(Sec)
Link 1(Sec)
Link 2(Sec)
Lead out Delay(Sec)
ABC Decode(Sec)
Displayed Digit
PTT Call at Inaudible
Group
Repeat
Link2
© June 2011 Icom America
Description
Sets the time period for the 1st digit code emission length when
the long tone function is specified in 5Tone Signaling-L for a
repeater, station or ID code in Zone screen.
Amount of time between when the radio begins transmitting and
the first ID code digit is sent out.
Amount of time between each digit of the 5 tone code
Amount of time between each digit of the 5 tone code.
Amount of time between the transmission of the last 5 tone digit
and the end of transmission.
The amount of time the radio waits to decode before it transmits
an answer back call code.
Determines the number of digits of the 5 tone ID that are shown
on the radio display.
When set to ON, the PTT button becomes active regardless of
the mute state.
The decoder accepts this code regardless of the code
programmed into the radio.
Used when the same codes are repeated. (e.g. 11111 ->
1E1E1)
Emits this code instead of no modulation between the station
and ID codes.
21
