Yealink ZVC Series Zoom Rooms Kit
for Mac-ZR
Yealink Network Technology CO., LTD
Yealink ZVC Series Zoom Rooms Kit for Mac-ZR Quick Start Guide
V30.21
English | 简体中文

Advertisement

loading
Need help?

Need help?

Do you have a question about the ZVC Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Yealink ZVC Series

  • Page 1 Yealink ZVC Series Zoom Rooms Kit for Mac-ZR Yealink Network Technology CO., LTD Yealink ZVC Series Zoom Rooms Kit for Mac-ZR Quick Start Guide V30.21 English | 简体中文...
  • Page 2 Introduction Yealink supports the ZVC800 Zoom Rooms Kit for Mac-ZR, ZVC500 Zoom Rooms Kit for Mac-ZR, and ZVC300 Zoom Rooms Kit for Mac-ZR for Yealink Solution for Zoom Rooms. The Mac mini communicates with CP960 connected to the same local area network via micro USB cable.
  • Page 3 Assembling the CP960 1a. Connect the power and wired network. 7.5m 1b. Connect the power and wireless network. 7.5m Wi-Fi Refer to Wireless Network Connection mentioned below in Configuring Your Phone for more information. 2(Optional). Connect the wireless microphone. 0.3m Micro USB Cable...
  • Page 4 Pairing the Zoom Rooms with CP960 Before using CP960 as the Zoom Rooms controller, you need to pair the CP960 (preload the Zoom Rooms Controller) with the Mac mini (preload the Zoom Rooms app). Procedure 1. Run the Zoom Rooms app on your Mac mini. The pairing code will be displayed on the screen.
  • Page 5 5. Tap the Speaker field and then select CP960 as your audio output device from the SOURCE field. Generally, you can use the Yealink solution for Zoom Rooms after pairing your phone with the Mac mini and setting your phone as an audio input and output device.
  • Page 6 Basic features on the home screen of the phone: After you sign into an account on your phone, more features are available on the phone. -Meet Now: Tap Meet Now to create an instant meeting. -Join: Tap Join to join a meeting by entering the meeting ID or personal link name.
  • Page 7 Using Hybrid Mode Yealink Solution for Zoom Rooms supports the hybrid mode that allows you to switch between SIP mode and Zoom Rooms mode to experience Zoom video conferences as well as SIP calls and conferences.
  • Page 8 4. Long press the mute key on the CPW90 for 5 seconds. The CPW90 is registered with the CP960 conference phone automatically. For more information about the instructions of Mute LED indicator on the CPW90, refer to Yealink CPW90 Quick Start Guide.
  • Page 9: Troubleshooting

    Troubleshooting The Possible Reasons Why the Phone Cannot Be Paired with the Mac mini -Ensure that the phone and Mac mini are connected to the same LAN. -Ensure that the phone can access the Internet. Checking Whether the Phone Can Access the Internet If it prompts that failed to pair and make sure that this tablet is connected to the Internet after you enter the pairing code on the phone, you need to check whether the phone can access the Internet.
  • Page 10 Zoom Rooms版本的CP960通过micro USB线与接入同一局域网的Mac mini进行通信连接, 并可作为Zoom Rooms控制器, 扬声器和麦克风。 Zoom Rooms app需预装在Mac mini上。 UVC80/UVC50/UVC30摄像机即插即用。 确保CP960和Mac mini可访问外网。 Yealink UVC80 (UVC80 可由UVC50/UVC30代替) Micro USB口 Yealink CP960 USB转HDMI适配器 USB2.0 ZOOM ZOOM HDMI 显示器1 显示器2 HDMI 局域网 HDMI Mac mini 我们要求使用Yealink原装PoE电源 ( 54V/0.56A) , 所有设备单独供电。 如果电源线或网线破皮, 请立即更换。...
  • Page 11 安装CP960话机 1a. 连接电源和有线网线。 7.5m 1b. 连接电源和无线网络。 7.5m Wi-Fi 想要了解更多信息, 请参考 配置话机 章节中的 无线网络连接 。 2(可选).连接有线扩展麦CPE90。...
  • Page 12 CP960与Zoom Rooms配对 CP960作为Zoom Rooms控制器前, 你需要将CP960 ( 预装Zoom Rooms Controller) 和Mac mini(预装Zoom Rooms app)配对。 过程 1.在Mac mini上运行Zoom Rooms app。 配对码显示在显示器上。 2.在CP960上输入配对码。 CP960(Zoom Rooms Controller)与mini-PC(Zoom Rooms app)配对成功。 如果当前CP960不是Zoom版本, 你需要先导入证书升级到Zoom版本。 想要了解更多信息, 联系你的管理员。 将CP960作为音频输入和输出设备 CP960与Mac mini配对后, CP960将作为系统默认的音频输入和输出设备。 过程 1. 在CP960上, 按 。 2. 关闭锁定设置。 你需要输入会议室密码才能更改该配置。...
  • Page 13 3. 选择麦克风, 在设备列表区域选择CP960作为音频输入设备。 4. 关闭软件音频处理。 此功能关闭后, 可以体验到更好的音频效果。 5. 选择扬声器, 在设备列表区域选择CP960作为音频输出设备。 正常情况下, CP960与Mac mini配对, 并将CP960设置为音频输入和输出设备后, 你可以开始 使用Zoom Rooms解决方案。 有关CP960的更多信息, 请阅读以下内容。 将CP960作为Zoom Rooms控制器使用 CP960与Mac mini配对后, 可作为Zoom Rooms控制器使用。 在CP960上登录Zoom Rooms账号 过程 1. 按登录。 2. 输入电子邮件地址和密码。 3. 按登录。 账号同时自动登录Zoom Rooms app。 在CP960上登出Zoom Rooms账号 过程 1.
  • Page 14 CP960上可操作的基本功能: 在CP960上登录帐户后, 你可以使用以下基本功能: -开始会议: 按开始会议创建一个即时会议。 -加入: 按加入, 通过输入会议ID或个人标签加入会议。 -电话: 按电话呼出一路通话。 -演示: 按演示开始共享屏幕。 按 检查已连接麦克风, 扬声器和摄像头的状态并配置 相关设置。 在 ->关于路径下, 你还可以查看控制器版本, Zoom Rooms版本和控制器IP。 -控制摄像机: 会议中, 按控制摄像机可调整摄像机焦距和角度。 配置CP960 通过Web界面配置CP960 访问Web界面: 1. 从屏幕顶部向下滑动, 进入设备设置中心。 2. 按状态查看话机的IP地址。 3. 打开电脑上的网页浏览器, 在地址栏里输入话机的IP地址 ( 例如: http://192.168.0.10或 192.168.0.10) , 按Enter键。 4.
  • Page 15 通过话机界面配置CP960 CP960话机设备设置中心 从屏幕顶部向下滑动, 进入设备设置中心。 时间和日期 显示无线麦图标和连接的无线麦个数 按相应的图标, 快速开启或关闭对应的功能或 进入功能设置界面 向左或向右滑动某一通知消息删除该消息 删除所有通知消息 显示所有通知消息 网络配置: 在话机设备设置中心界面, 点击设置->网络为话机配置网络。 无线网络连接: 1. 在话机设备设置中心界面, 点击设置->无线网络。 2.开启无线网络。 话机将自动搜索附近可用的Wi-Fi。 3.从可用的网络列表中, 选择一个Wi-Fi。 4. 如果要连接一个加密的网络, 在密码区域中输入密码, 再按连接。 自定义CP960: 在话机设备设置中心界面, 按设置设置CP960话机显示语言, 时间和日期, 背光灯亮度与激活时间和屏保激活时间与屏保类型。 使用混合模式 亿联Zoom Rooms解决方案支持混合模式, 使你可以在SIP模式和Zoom Rooms模式之间 任意切换, 让你既可以体验Zoom视频会议也可以使用SIP通话和会议。 SIP模式下 , 你可以使用基本通话功能, 包括拨打、 接听电话、 发起会议、 录制呼叫等。 开启混合模式...
  • Page 16 切换SIP模式与Zoom Rooms 模式 启用混合模式后, 你可以快速切换SIP模式和Zoom Rooms模式。 过程 1. 在Zoom Rooms模式空闲界面, 按悬浮球切换至SIP模式。 2. 在SIP模式空闲界面, 按悬浮球或桌面的Zoom Rooms app图标切换至Zoom Rooms模式。 故障排除 CP960与mini-PC无法配对 -确保Yealink插件版本与CP960话机版本匹配。 -确保话机可访问外网。 检查CP960话机是否可以访问外网 在CP960上输入配对码后, 若提示配对失败, 确保话机连接到Internet。 请检查话机是否 可以访问外网。 过程 1. 在话机网页界面, 点击网络配置->诊断。 2. 从命令下拉框选择Ping。 3. 在IP地址区域输入Zoom.us。 4. 点击开始。 如果话机无法访问外网, 请联系你的管理员为话机开放访问外网权限。...
  • Page 17 Yealink is a global leading provider of enterprise communication and collaboration solutions, offering video conferencing service to worldwide enterprises. Focusing on research and development, Yealink also insists on innovation and creation. With the outstanding technical patents of cloud computing, audio, video and image processing technology, Yealink has built up a panoramic collaboration solution of audio and video conferencing by merging its cloud services with a series of endpoints products.

This manual is also suitable for:

Zvc500Zvc300
