- Page 1 MeetingBar A40 Deployment & Connection MeetingBar A40 Deployment & Connection MeetingBar A40 Deployment & Connection Package Contents Package Contents TIP For the MeetingBar A40 unboxing video, please refer to Video: MeetingBar A40 Unboxing...
- Page 2 MeetingBar A40 Deployment & Connection Install MeetingBar A40 Install MeetingBar A40 Mount on a Wall Mount on a Wall 1. Determine A40 Position 1. Determine A40 Position The mounting height affects your camera view. The recommended installation height is 110 cm above the ground, and the distance between the A40 and the TV should be greater than 1 cm.
- Page 3 MeetingBar A40 Deployment & Connection Mount above a TV or Display Mount above a TV or Display NOTE NOTE The M-2 bracket can be inserted into the M-1 bracket in two directions. This illustration focuses on one direction. Due to the device's weight, avoid mounting on slim TVs to prevent potential falls or screen damage.
- Page 4 MeetingBar A40 Deployment & Connection Place on a Flat Surface Place on a Flat Surface...
- Page 5 MeetingBar A40 Deployment & Connection Embed in the Wall Embed in the Wall NOTE NOTE Mounting height affects your camera view. The recommended installation height is 110 cm above the ground. Keep the front of the A40 flush with the wall surface.
- Page 6 MeetingBar A40 Deployment & Connection Adjust Camera Tilt Adjust Camera Tilt Understand Each Port Understand Each Port Refer to Hardware Introduction for details. Connect/Pair MeetingBar A40 Connect/Pair MeetingBar A40...
- Page 7 For optimal pairing, connect Yealink MeetingBar and then Yealink CTP Touch Panel. The Yealink CTP Touch Panel can be powered via PoE. Yealink MeetingBar and Yealink CTP Touch Panel must be on the same LAN or connected to the same Wi-Fi.
- Page 8 MeetingBar A40 Deployment & Connection Understand the LED Status Understand the LED Status MeetingBar LED Status MeetingBar LED Status Description Description The device is not powered on. The device is initializing. Solid green The device is working (calling/sharing content). Flash green The device has incoming calls.
