Quick Setup
Quick Setup
Before starting the setup, ensure that you have completed steps in
1. Setup Wizard
1. Setup Wizard
After booting up the Yealink MeetingBar for the first time or restoring it to factory settings, it will enter the startup
wizard interface.
Step 1 Select Control Method
Step 1 Select Control Method
Method 1: Use the Yealink Remote Control
Method 1: Use the
Yealink Remote Control
Press the OK
OK key on the Yealink Remote Control three times to proceed to
Method 2: Use the Yealink CTP Touch Panel
Method 2: Use the
Yealink CTP Touch Panel
1. After the Yealink CTP Touch Panel is turned on for the first time or restored to factory settings, you must
change the administrator password.
By toggling on Set this password as system's password
Set this password as system's password , the Yealink MeetingBar will synchronize the modified
password with the Yealink CTP Touch Panel.
 NOTE
NOTE
Ensure that the Yealink CTP Touch Panel is on the same LAN as the Yealink MeetingBar.
Deployment and Connection
Step 2 Initialize
1
Quick Setup
.
Configuration.

Advertisement

loading
Need help?

Need help?

Do you have a question about the MeetingBar A40 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Yealink MeetingBar A40

Summary of Contents for Yealink MeetingBar A40

  • Page 1 Deployment and Connection 1. Setup Wizard 1. Setup Wizard After booting up the Yealink MeetingBar for the first time or restoring it to factory settings, it will enter the startup wizard interface. Step 1 Select Control Method Step 1 Select Control Method...
  • Page 2 Quick Setup 2. If using a combination kit or connecting the Yealink CTP Touch Panel directly to the Yealink MeetingBar with a network cable, the Yealink CTP Touch Panel will automatically pair with the Yealink MeetingBar. If the Yealink CTP Touch Panel is purchased separately, pair it manually by entering the Yealink MeetingBar's IP address on the Yealink CTP Touch Panel.
  • Page 3 Language and select Next Step Next Step. 2. Configure a wired or wireless network, then select Next Step Next Step.  NOTE NOTE When connected to a network cable, the IP address appears in the lower-left corner of the Yealink MeetingBar display.
  • Page 4 Advanced Network for Advanced Network Configuration. Alternatively, connect to a wireless network by selecting the Wi-Fi network and entering the password.  NOTE NOTE When connected to both a network cable and Wi-Fi, the Yealink MeetingBar prioritizes the Wi-Fi connection.
  • Page 5 Quick Setup 3. Set up Time Zone Time Zone and select Next Step Next Step. 4. Auto Update: Enable Auto Update Auto Update after reviewing the terms. Enabling this is recommended for future updates.

  • Page 6: Firmware Version

    Check Firmware Version Check Firmware Version Check the firmware version to see if an update is needed. On the Yealink CTP Touch Panel or using the Yealink Remote Control , navigate to More More > Settings Settings > Device Settings Device Settings >...
  • Page 7 Quick Setup Update Firmware Update Firmware 1. Go to More More > Settings Settings > Device Settings Device Settings > Upgrade Upgrade (default password: 0000) > Firmware Update Firmware Update > Check for Check for Update to see if an update is available. Update 2.
  • Page 8 Yealink CTP Touch Panel and Yealink MeetingBar. Log in to Yealink MeetingBar Log in to Yealink MeetingBar  NOTE NOTE Use the Yealink Remote Control if your display does not support touch.
  • Page 9 Quick Setup Pairing (Optional) Pairing (Optional) Enter the pairing code from the Yealink MeetingBar display on the Yealink CTP Touch Panel. 4. Set Up Yealink MeetingBar 4. Set Up Yealink MeetingBar Camera Settings Camera Settings On the Yealink CTP Touch Panel or using the Yealink Remote Control , select More More >...
  • Page 10 Confirm Password Confirm Password, then select Save Save. Device Name Settings Device Name Settings Go to More More > Settings Settings > Device Settings Device Settings > General General > Device Name Device Name to set the Yealink MeetingBar name.

  • Page 11: Performance Test

    About on the Yealink CTP Touch Panel or using a Yealink Remote Control . 2. In a browser, enter "https://[MeetingBar or Yealink CTP Touch Panel IP address]," for example: https://10.50.56.1/. 3. Enter the user name and password (default: admin; default password: 0000), then click Log in Log in.
  • Page 12 Cannot log in to Teams in Yealink MeetingBar Cannot log in to Teams in Yealink MeetingBar? ? When the Yealink MeetingBar logs in to the Teams account, you can check according to Android Bar cannot log in to the Teams account.
