- Page 1 MeetingBar A30 Deployment & Connection MeetingBar A30 Deployment & Connection MeetingBar A30 Deployment & Connection Package Contents Package Contents TIP For the MeetingBar A30 unboxing video, please refer to Video: MeetingBar A30 Unboxing...
- Page 2 MeetingBar A30 Deployment & Connection Remove Protective Shell Remove Protective Shell Install MeetingBar A30 Install MeetingBar A30 Mount it on a wall Mount it on a wall 1. Determine MeetingBar A30 position 1. Determine MeetingBar A30 position The mounting height affects your camera view. The recommended height is 1.1 m above the ground.
- Page 3 MeetingBar A30 Deployment & Connection NOTE NOTE Embedded installation is prohibited (For example: inside the wall, enclosed space). 2. Install mounting bracket 2. Install mounting bracket Step 4: Expansion Screws: φ6 * 30 mm. Hole depth: 6 mm, Hole diameter: 30 mm.
- Page 4 MeetingBar A30 Deployment & Connection 3. Mount it to bracket 3. Mount it to bracket Screws: 1/4’’ -20 UNC Mount it on TV stand cart platform Mount it on TV stand cart platform Put it on a desk Put it on a desk...
- Page 5 Connect/Pair MeetingBar A30 For a better pairing experience, we recommend starting the MeetingBar A30 first and then the CTP18. The MeetingBar A30 and CTP18 must be on the same LAN or connected to the same Wi-Fi before pairing and completing the setup.
- Page 6 MeetingBar A30 Deployment & Connection NOTE NOTE If you only use one display, please connect to HDMI 1 port. The functions of the VC hub/phone port and the VC Hub/ Internet port are different, and please pay attention to the connection method when using.
- Page 7 MeetingBar A30 Deployment & Connection How do I connect VCM36-W with the MeetingBar A20/A30? How do I connect VCM36-W with the MeetingBar A20/A30? How do I pair CPW90 with the MeetingBar A20/A30 Teams? How do I pair CPW90 with the MeetingBar A20/A30 Teams?
