Veracity PPM (Wired to RC Controller) Operation

The Veracity Control Wheels stream a PPM (Pulse Position Modulation) signal that is standard on many RC controllers.
They are designed to interface with the 'trainer' port commonly available on RC controllers. Look in the appendices for
notes on specific RC models and setting up the trainer port. The Veracity Control Wheels use the following channels for
the data stream. These assignments are fixed into the Veracity Control Wheels' firmware and cannot be changed.
Channel Assignments
PAN Wheel
TILT Wheel
ROLL Wheel
Set up your RC system so that the above channels are driving the camera mount axis that you wish to control.
Once the RC system is properly configured, make sure the trainer port is active and you should be able to monitor the
wheels' output signals on the RC controller screen using a function like "Monitor" or "Servo Setup". Once you can see
the above channels signal levels moving in response to wheel movement then Veracity Control Wheels are working.
It is easiest to get your gimbal working with the RC system joysticks, and then enable the trainer port and use the
wheels as a joystick replacement. If you cannot get the gimbal to function without the trainer port enabled, then there is
likely an additional issue with the system that is preventing operation. Connecting the wheels will not likely fix such an
issue.
To connect to any gimbal that uses Spektrum radios like a MoVI gimbal, Gremsy or Letus you will need to use a
Spektrum Radio Controller. Please see the setup on the following appendices.
See Appendix 1 - Setting up with your DX9 Spektrum Radio.
See Appendix 2 - Setting up with your DX7S Spektrum Radio.
See Appendix 3 - Setting up with your DX18 Spektrum Radio.
To connect to any gimbal that uses Futaba radios like a DJI Ronin or Tilta gimbal you will need to use a Futaba Radio
Controller. Please see the setup on the following appendix.
See Appendix 4 - Setting up with your Futaba T14SG Radio.
Copyright © 2017
Page 8
Aileron (Channel 2)
Elevator (Channel 3)
Rudder (Channel 4)
