1. Features

DAEnetIP2 v2 is a multifunctional Ethernet device (IP controller) for management and control. It
could be used for industrial and home automation, access control, fire and security systems or
embedding in other systems. It is also suitable for controlling relay boards and tracking different
sensors via internet.
DAEnetIP2 v2 is the newer and improved version of the popular DAEnetIP2.
 10/100 Mb Ethernet interface with Link/Activity Led
 Auto-MDIX
 Power supply 7.5 - 25VDC
 Low power consumption (<50mA/12V)
 8 analog inputs with 10 bit resolution (0-3.3VDC) (no pull-up or pull-down resistors)
 16 (2x8) bit configurable digital I/O port (0-3.3VDC)
 Standard protocols: ARP, IP, ICMP (ping), DHCP
 Supports snmp v1 (snmpset, snmpget, snmptrap), HTTP (web server with authorization)
 Configurable ports numbers for SNMP (161) and HTTP (80)
 Two MAC addresses configurable for access protection
 Configuration via SNMP requests or web browser
 Integrated WEB server for all functions/parameters access
 Reset of the digital outputs on incoming/outgoing ping timeout
 Function "load outputs states from EEPROM on boot"
 Each I/O line can be named by user via web browser
 It can send traps according analog ADC level
 An analog inputs may be referred to control one digital output according its input level
 Working temperature range: 0ºC to 70ºC
