5.2. DAEnetIP2 v2 ports description
Port JP3 (P3)
digital outputs
Pin N Bit Func
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
9 -
10 -
Legend:
o "Free" – the pin is free to be used by user.
o "XXXXXX" - the pin is reserved for special function – cannot be accessed.
o "In" – the pin is digital input
o "Out" – the pin is digital output
o "I/O" – the pin is digital input or output depending the settings
o "Ain" – analog input
Dir Bit
Free I/O 1
Free I/O 2
Free I/O 3
Free I/O 4
Free I/O 5
Free I/O 6
Free I/O 7
Free I/O 8
GND PWR -
GND PWR -
Port JP4 (P5)
digital outputs
Func Dir
Free I/O
Free I/O
Free I/O
Free I/O
Free I/O
Free I/O
Free I/O
Free I/O
+3.3V PWR
GND PWR
DAEnetIP2 v2 User Manual
Table 5.1. I/O Ports
Port JP5 (P6)
(digital/analog inputs)
Bit Func
1 Free
2 Free
3 Free
4 Free
5 Free
6 Free
7 Free
8 Free
- +3.3V(Vref)
- GND
21 Apr 2020
Dir
Ain
Ain
Ain
Ain
Ain
Ain
Ain
Ain
PWR
PWR
