TruXedo Lo Pro QT Owner's Manual

Invis-A-Rack Rail & J Hook
Lo Pro QT Replacement Cover 12 ___*___ _______*________
1 ___*___ TruXedo ®
13 1705052 End Plug, 1" OD
2 ___*___ Black Front Header
14 ___*___ Black Bow
3 ___*___ Header Seal, Notched
15 1702992 Spring Plunger, 5/8" x 2.15"
4 1117540 Front Header 08 End Plugs (Set of Two)
5 1704604 Header Guide_QT 16 1703260 Tension Control Bracket
17 1115354 Header Insert Safety Clip
6 * *
18 ___*___ Hook and Loop Fasteners
7 ___*___ Safety Strap
19 1703332 Hitch Pin, 1/16" x 1 5/16"
8 1700428 Washer Flat 5/16"
20 1705079 Aluminum Clamp Half
9 1704606 Cap Screw, 5/16-18 x 5/8"
21 ___*___ Side Rail, Passenger's Side
10 1117591 Header Guide Retainer.
22 ___*___ Side Rail, Driver's Side
11 1704715 Extruded Retainer Loop
23 1114773 Flat Spring, 5/8" x 3 7/8"
24 1704213 Latch Assembled
25 1702926 Cap Screw, 5/16" x 7/8"
26 1704187 Header Stop
27 1115373 Side Rail End Plugs w/Seal (Set of Two)
28 1704383 Filister Head Screw
29 1117467 Rear Header 08 End Plugs (Set of Two)
30 ___*___ Black Rear Header
31 1704194 Weld Nut 5/16-18 ZP
32 1701059 Self Tap Screw 5/16-18 x 1"
33 1117810 Block Seal
34 1117811 D Seal
* Please specify length or make and model of vehicle.
DIRECT ALL WARRANTY CLAIMS TO TRUXEDO AT 1-877-878-9336
Product Purchased:
Name:_______________________________________
□ Original TruXedo
Address:_____________________________________
□ TruXedo Lo Pro QT
City:____________________State:_____Zip:________
□ TruXedoPlus
Phone Number:________________________________
□ TruXport
Email Address:________________________________
□ TruXedo Deuce
Date Purchased: ___________ Price Paid: _________
□ TonneauTraX
Dealer Name:_________________________________
□ TonneauMate
Pickup Make: _________________________________
□ Edge
Model: ________________________ Year: ________
