TruXedo PRO X15 Owner's Manual

P/N 1118548 REV A
A
Cover Assembly
E
Main Parts Hardware Bag, Showing Components Inside This Hardware Bag.
1118539-hardware bag. Fasteners
needed to mount the rear brackets
for trucks WITH and WITHOUT the
Trail Rail System.
1706274
Front Passenger
Bracket
Truxedo, Inc. 2209 Kellen Gross Drive Yankton, SD 57078 (1-877-878-9336) www.truxedo.com
-
Please read manual throughly before installing this kit.
Failure to install cover properly will void wrarranty.
- Use picture keys below to verify componets found in shipping
box and hardware bags.
- Damaged or missing parts? Call 1-877-878-9336 Mon - Fri 8 am-5
pm CT. Parts will be shipped to you factory direct. Do not return kit
to place of purchase.
Components In Shipping Box:
B
Driver Side Rail
Components Inside Hardware Bag "E", p/n 1118547:
Main Parts Bag
Mounting brackets for both Trail Rail and Non-Trail Rail Cargo
Management Systems are located in this hardware bag.
1706273
Rear Driver/ Passenger
Front Driver Bracket
Bracket
OWNER'S MANUAL
C
Passenger Side Rail
1118540-hardware bag. Side
Rail Attachment Hardware for
Both Trail Rail and Non-Trail
Rail Truck Boxes.
1118547
(Qty. 2)
1706275
Non-Trail Rail Spacer
Bracket, Driver Rear
Page 1
D
Weather Seal Hardware
Bag
1118538-hardware bag. Fasteners
needed to mount the front brackets
for trucks built BEFORE July 2020.
1706041-hardware bag. Fasteners
needed to mount the front brackets
for trucks built AFTER July 2020.
1706339
1706340
Non-Trail Rail Spacer
Bracket, Passenger Rear
