4.14.2. BATEC SHIFT LEVER of BATEC QUAD HYBRID

User adjustments
1. Push the pedal to find the point where maximum pressure inwards is
required – normally when crank arm is parallel to the ground.
2. Loosen the screw on the crank ring.
