3.3.3. Parts of the controls for BATEC QUAD MANUAL

3
4
2
5
1
1. BATEC QUAD GRIPS
2. BATEC SHIFT LEVER
3. Back pedal brake
4. Hub gear shifter
5. BATEC MAGIC LEVER
