Disposing of the battery
As with all batteries, the Batec Mobility batteries must be disposed of
properly. Check with your local waste-management centre. Contact Batec
Mobility if you have any doubts.

4.15.4. TECHNICAL SPECIFICATIONS OF THE 280 WH BATTERY

• Dimensions: 350 x 140 x 60 mm
• Weight: 2.6 kg
• Power: 280 Wh
• Voltage: 36 V
• Maximum discharge current: 29 A
•
Maximum charge current: 5 A
• Internal resistance: 200 mOhm
• BMS consumption: < 0.2 mA when on; < 0.02 mA when off
• Battery range by model:
o
o
o
o

4.15.5. TECHNICAL SPECIFICATIONS OF THE 522 WH BATTERY

• Dimensions: 350 x 140 x 60 mm
• Weight: 4 kg
•
Power: 522 Wh
• Voltage: 36 V
• Maximum discharge current: 29 A
•
Maximum charge current: 5 A
• Internal resistance: 200 mOhm
• BMS consumption: < 0.2 mA when on; < 0.02 mA when off
• Battery range by model:
o
o
o
o
USER MANUAL
BATEC URBAN / BATEC ELECTRIC: 27 km*
BATEC MINI: 22 km*
BATEC RAPID: 20 km**
BATEC HYBRID: 27-40 km***
BATEC URBAN / BATEC ELECTRIC: 50 km*
BATEC MINI / BATEC ELECTRIC 2 / BATEC SCRAMBLER: 40 km*
BATEC RAPID: 40 km**
BATEC HYBRID: 50-75 km***
