4.12. USING THE BATEC QUAD MANUAL CONTROLS
4.11.1. BATEC QUAD GRIPS of BATEC QUAD MANUAL
User adjustments
1. Adjust to wrist vertically. Tighten screw to 20 Nm.
2. Adjust to wrist horizontally. Tighten screw to 20 Nm.
USER MANUAL
1
PAGE
74 / 119
NUMBER/VERSION: MU-001/12.0
C/ Illa de Buda, 2 (P.I. Sud-Oest)
08192 Sant Quirze del Vallès [Barcelona - Spain]
www.batec-mobility.com
info@batec-mobility.com
2
APPLICATION DATE: 10/10/19
T +34 935442003
