1. Crank arms

3.4.2. Parts of the BATEC HYBRID

2. Main control panel
3. BATEC SAFE-FEET stand
frame
4. Rear lights
5. Weights
6. Brake calipers
7. Disc brake
8. Tyre
9. Rim
10. Front light
11. Battery
12. Anchor lever
13. Chain
14. Derailleur
15. Motor
16. Weight
17. Rear wheels
18. SAFE-FEET stand frame
19. Anchoring bar
20. Detaching ramp
