ADF Web HD67B19-B2 User Manual page 19

Industrial Electronic Devices
If the field "Enable DHCP" is checked, the converter acts as DHCP Server for the Clients connected. If the option is enabled, in the
fields "DHCP First IP Address" and
Time (seconds)" the required time for the renewing of the IP Address assigned to the Client is defined;
In the field "Max Client" the maximum number of Wi-Fi Clients accepted is defined;
In the field "Channel" the channel for Wi-Fi communication is defined.
The means of the fields for Client configuration are:
If the field "Obtain an IP Address
converter gets the IP Address using DHCP. Otherwise, the IP Address is
defined as static;
In the field "IP Address" the IP address of the converter is defined;
In the field "Subnet Mask" the SubNet Mask of the converter is defined;
In the field "GATEWAY" the default gateway of the net is defined. This
feature can be enabled or disabled pressing the Check Box field. This feature
is used for going out of the net;
In the field "DNS" the DNS address is defined. This field is required if the
server address is define by URL and not IP Address.
In the field "Port" the port used for MQTT communication is defined;
In the field "SSID" the name of the Wi-Fi network to connect is defined;
In the field "Password" the password used to connect to the Wi-Fi network
is defined.
ADFweb.com Srl – IT31010 – Mareno – Treviso
"DHCP SUBNET Mask" the IP Addresses range used for DHCP is defined. In the field
automatically" is checked, the
User Manual OPC UA Client / MQTT
Document code: MN67B19_ENG Revision 1.000
Figure f "Set Communication
INFO: www.adfweb.com
Page 19 of 35
"Lease
 Wi-Fi" window
