- Page 1 User Manual PCE-SLM 10 Sound Level Meter User manuals in various languages (français, italiano, español, português, nederlands, türk, polski, русский, 中文) can be found by using our product search on: www.pce-instruments.com Last change: 17 July 2020 v1.0 © PCE Instruments...
-
Page 2: Table Of Contents
Contents Safety notes ................... 1 Delivery contents .................. 2 Specifications ..................2 Device description ................3 Switching the meter on and off ............4 Alarm function ..................4 Switch alarm function on and off ..................4 Data storage ..................4 Menu ....................... -
Page 3: Safety Notes
Safety notes Please read this manual carefully and completely before you use the device for the first time. The device may only be used by qualified personnel and repaired by PCE Instruments personnel. Damage or injuries caused by non-observance of the manual are excluded from our liability and not covered by our warranty. -
Page 4: Delivery Contents
Delivery contents 1 x sound level meter PCE-SLM 10 1 x micro USB cable 1 x user manual Specifications Measurement range 30 ... 130 dB Accuracy ±1.5 dB (at 94 dB and 1 kHz) Frequency range 31.5 Hz ... 85 kHz... -
Page 5: Device Description
Device description Wall mounting brackets PC connection and power supply Alarm LED Microphone sensor Display ¼ inch connection for tripod mountings 3.5 mm speaker connection Adjusting screw Keys Symbol Function Description On / off key, back Press to switch on the meter. Press and hold to turn off the meter. -
Page 6: Switching The Meter On And Off
Switching the meter on and off To turn on the meter, press the key. The meter turns on immediately and starts measuring after two seconds. When you connect the power supply, the meter also turns on automatically. To turn off the meter, press and hold the key for two seconds. -
Page 7: Software
Software With the sound software you can download and analyse the stored data. A live view is also possible with the software. Here you can start a live measurement. A new window will open in the software. Here you can download the stored measurement data from the noise meter. A new window will open in the software. -
Page 8: Window: Live Measurement
Window: Live measurement Description Start and stop a live measurement. Delete a measurement series. Save the measurement series to the PC. This is only possible when the live measurement is stopped. File format: "lab" Print graph. This is only possible when the live measurement is stopped. Here you can zoom into the graph. -
Page 9: Window: Data Readout
Window: Data readout Description Start and stop a live measurement. Save the measurement series on the PC. This is only possible when the live measurement is stopped. File format: "lab" Print graph. This is only possible when the live measurement is stopped. Here you can zoom into the graph. -
Page 10: Warranty
Warranty You can read our warranty terms in our General Business Terms which you can find here: https://www.pce-instruments.com/english/terms. Disposal For the disposal of batteries in the EU, the 2006/66/EC directive of the European Parliament applies. Due to the contained pollutants, batteries must not be disposed of as household waste. They must be given to collection points designed for that purpose. - Page 11 PCE Instruments contact information Germany France Spain PCE Deutschland GmbH PCE Instruments France EURL PCE Ibérica S.L. Im Langel 4 23, rue de Strasbourg Calle Mayor, 53 D-59872 Meschede 67250 Soultz-Sous-Forets 02500 Tobarra (Albacete) Deutschland France España Tel.: +49 (0) 2903 976 99 0 Téléphone: +33 (0) 972 3537 17 Tel.
