4K HDR 4:4:4 60Hz HDBaseT2.0 Receiver with USB
Device Inputs, Ethernet & PoH (4K: 100m/328ft)
RX-700
WyreStorm recommends reading through this document in its entirety to become familiar with the product's features prior to starting the
installation process.
IMPORTANT! Installation Requirements
• Visit the product page to download the latest firmware, document
versions, additional documentation, and configuration tools.
• Read through the
Wiring and Connections
guidelines before creating or choosing premade cables.
• While this product supports CEC, WyreStorm cannot guarantee
compatibility with all forms of CEC communication.
Basic Wiring Diagram
Touchscreen
Tablet
Copyright © 2020 WyreStorm Technologies |
RX-700 Quickstart Guide | 200331
section for important wiring
KEY
Personal Computer
SW-130-TX-US
wyrestorm.com
In the Box
1x RX-700 Receiver
1x IR Emitter
1x IR Receiver
1x 3-pin Terminal Block
1x 12V DC 3A Power Supply (US/UK/EU/AU)
2x Mounting Brackets
1x Quickstart Guide (This Document)
HDMI/DisplayPort/USB-C
HDBaseT
RS-232
Analog Audio
USB 2.0
RX-700
Short Throw
Projector
Interactive
Whiteboard
1 of 4
Quickstart Guide
Amplifier
USB Camera
UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973)
