- Page 1 PDF provided by Conference Room AV WyreStorm RXV-70-4K-G2 4K HDR HDBaseT Receiver for MXV Matrix - RS-232 and PoH...
-
Page 2: Basic Wiring Diagram
4K HDR HDMI-Over-HDBaseT Receiver with HDCP 2.2 and PoH Quickstart Guide RXV-70-4K-G2 v1 WyreStorm recommends reading through this document in its entirety to become familiar with the product’s features before beginning the installation process. In the Box IMPORTANT! Installation Requirements 1x RXV-70-4K-G2 Receiver •... -
Page 3: Front Panel
19-pin type A HDMI female HDMI Out Supports HDMI and DVI/D with adapter Copyright © 2019 WyreStorm Technologies | wyrestorm.com UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973) 2 of 4 RXV-70-4K-G2 v1 Quickstart Guide | 190620 Email: support@wyrestorm.com... -
Page 4: Wiring And Connections
Wiring and Connections WyreStorm recommends that all wiring for the installation is run and terminated prior to making connections to the switcher. Read through this section in it’s entirety before running or terminating the wires to ensure proper operation and to avoid damaging equipment. -
Page 5: Specifications
Safety and Emission CE | FCC | RoHS | RCM Note: WyreStorm reserves the right to change product specification, appearance or dimensions of this product at any time without prior notice. Warranty Information This product is covered by a 5-year limited parts and labor warranty. During this period there will be no charge for unit repair, component replacement or complete product replacement in the event of malfunction.
