Town & Country Fireplaces King-TC Installation Manual

European Copper Decorative caps.
Models King-TC, Pawn-TC, Bishop I-TC
and Bishop II-TC have been tested and are
approved for use with all Town and Country
fireplaces that are vented vertically through
the roof.
Only models with the "TC" extension will fit
Town and Country Terminals. These shrouds
are designed with the cap internal shield re-
moved to allow the "TC" Termination Cap to
fit up inside the shroud cap.
Check with your local building code agency
before you begin installation to ensure com-
pliance with local codes including the need
for permits and follow-up inspections.
311008-2
EuropEan CoppEr DECorativE Cap
Models: King-TC, Pawn-TC, Bishop l-TC & Bishop ll-TC
For Direct Vent Termination Caps
Fig #1
24.00"
KING-TC
Fig #3
20 "
5/8
PAWN-TC
EUROPEAN COPPER DECORATIVE CAP
Fig #2
47 "
3/4
BISHOP l-TC
Fig #4
25 "
3/4
BISHOP ll-TC
52 "
1/16
26.00"
38 "
5/8
20"
