INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
These instructions are supplementary to the Installation and
Operating Instructions supplied with the fireplace and should be
kept together. Refer to the Installation and Operating Instructions for
proper gas supply, safety requirements and operating instructions
Visit www. townandcountryfireplaces.com for the most recent version of this manual
150223-16
TC42
HEARTWOOD
BURNER KIT
INSTALLATION
INSTRUCTIONS
SKU#22150038
For TC42 Series D
Fireplaces
SKU# 22150038
100000363-50

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TC42 and is the answer not in the manual?

Questions and answers

Related Manuals for Town & Country Fireplaces TC42

Summary of Contents for Town & Country Fireplaces TC42

  • Page 1 Refer to the Installation and Operating Instructions for proper gas supply, safety requirements and operating instructions TC42 HEARTWOOD BURNER KIT INSTALLATION INSTRUCTIONS SKU#22150038 For TC42 Series D Fireplaces Visit www. townandcountryfireplaces.com for the most recent version of this manual 150223-16 SKU# 22150038 100000363-50...

  • Page 2: Contents Of Package

    Contents of Package • Burner assembly (including pilot and manifold) • Log grate • TC42 Heartwood logs • Ember pieces (one bag) • Coal chunks (one bag) • Ember wool (one bag) • Hardware package If this fireplace is to be used on Propane please convert prior to installtion.
  • Page 3 Burner/ Grate Installation 4. Attach the manifold gas and pilot supply tubes to the bulk head fitting and tighten (Figure 5). 2 SCREWS Ensure that all connections are gas tight. Figure 5: Gas and pilot supply tubes. 5. Feed the ignition and sensor wires through the bulkhead plate (Figure 6) to the interface.
  • Page 4 6. Attach the ignition and sensor Flame sensor wires to the module (Figure 7). wire (white) Ignition wire (red) Interface module 7. Replace the access cover. Figure 7: Interface module. A panel set must now be installed. See Installation and Operating Instructions manual for details.
  • Page 5 Ember Material A large bag of ember wool is supplied with the Heartwood burner kit and needs to be installed on the burner to ensure Ember wool in this area only optimum performance and flame appearance. A bag of large coal chunks and small ember pieces are also supplied.
  • Page 6 Log Set Assembly Gas plumbing and vent connections should be completed before proceeding. The logs are fragile, and should be handled with care. Unpack and inspect log set. There should be a total of seven logs. Position the logs as indicated by the following pictures.
  • Page 7 Figure 13: Log 3 placement. Figure 14: Log 4 placement. SKU#22150038_150223-16 100000363-50...
  • Page 8 Figure 15: Log 5 placement. Figure 16: Log 6 placement. 100000363-50 SKU# 22150038_150223-16...
  • Page 9 Figure 17: Log 7 placement. Figure 18: Log 8 placement. Figure 19: Log 9 placement. SKU#22150038_150223-16 100000363-50...

  • Page 10: Propane Conversion

    Propane Conversion Note: The propane conversion kit is not included with the burner kit. The conversion kit is an option which must be ordered separately. If the unit is to be used with propane gas, convert the fireplace from natural gas as follows using the components supplied with this burner kit.
  • Page 11 4. With a ½” wrench remove the natural gas orifice (Figure 22). Install the propane orifice (marked “LE”) (Figure 23). 6. Fully open the primary air shutter. Figure 23: Orifice. Figure 22: Removing orifice. 7. Reinstall the manifold assembly. 8. With a 7/16” wrench loosen the pilot head on the pilot assembly by a half-turn (Figure 24) 9.
  • Page 12 Pilot Hole in sliding band adjustment indicates propane band gas con guration Figure 25: Pilot band in natural gas position. Figure 26: Pilot band in propane gas position. 10. Open the air shutter by following the steps in the “Burner Flame Adjustment” on page 13. 11.

  • Page 13: Burner Flame Adjustment

    Burner Flame Adjustment The air shutter on the burner tube controls the primary combustion air to the gas burner and is preset at the factory for natural gas fuel. Some adjustment may be necessary to obtain desired flame and to eliminate carbon deposits.

  • Page 14: Replacement Parts

    EMBER MATERIAL (Not shown) 1b ..BURNER INSULATION 1c ..BURNER TRAY SUPPORT SHIELD #3..ORIFICE, NATURAL GAS (#20) 1d ..PILOT SHIELD 1e ..TC42.NG01 BURNER WELD #4..PILOT ASSEMBLY, CONVERTIBLE 1f ..MANIFOLD 1g ..1/2 PIPE TO 1/2 TUBE CONNECTION #5..MAIN SUPPLY TUBE (FLEX) 1h ..PILOT BRACKET...
  • Page 15 SKU#22150038_150223-16 100000363-50...
  • Page 16 © 2016 Copyright Pacific Energy Fireplace Products LTD Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the copyright laws. For technical support, please contact your retailer. www.townandcountryfireplaces.net 2975 Allenby Rd., Duncan, BC V9L 6V8 Printed in Canada...
