FEATURES - FRONT PANEL
5
6
7
LEVEL: Input level control for each channel with unity gain
1.
setting at 12 o'clock.
EQ: Variable EQ for each input with bass, semi-parametric mid
2.
range, and high boost/cut controls.
FILTER: Three-position switch and variable control activates a
3.
notch filter for targeted frequency removal or a high-pass filter to
remove excessive low end rumble.
FX BLEND: Wet/dry control allows you to mix the original 'dry'
4.
input source with the 'wet' FX Loop returns.
FX LOOP ASSIGN: Selects whether guitar pedals in the FX Loop
5.
affect the signal on Input A, Input B, or both simultaneously.
FOOTSWICH ASSIGN: Used to set the Boost/FX Loop footswitch
6.
to activate the Boost, FX Loop, or both simultaneously.
BOOST: Sets the amount of clean boost applied when the Boost
7.
function is active. Up to +15dB of gain is available when this
control is turned fully clockwise.
Radial Engineering Ltd.
4 3 2
2
1
PZ-Pro™
