5. GRAPHIC REPRESENTATIONS

Figure 2 view of the external side
2
1
10
Possible passage for cables
The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using this information for any purpose other
than the use of the products or the execution of the project to which it refers and from communicating it to third parties without prior written agreement of Automatic Systems.
The document is subject to change without notice.
ClearLock 645
-UM-EN
3 4
5
6
9
7
8
12
13
1) -mechanic lock
2) -radar (optional)
(optional)
3) -electric key
4) -loudspeaker
5) -small light
6) -external push-button panel
7) -electric key (optional)
8) -badge reader (optional)
9) -stop button and intercom aid call
10) -RX (left)-TX (right) photocells
Figure 3 external push button panel
intercom function led
intercom button
red: manual
yellow: transit phase
green: open
opening button
microphone
12)- radar (optional)
13)- internal push-button panel
14)- RX (left)-TX (right) photocells
15)- fastening screws (n°2 int+n°2 est)
red: manual
yellow: transit phase
green: open
