FIGURE 12 BOOTH PRE-STARTING
Figure 12 booth pre-starting
C
C
A - Nut to adjust the height of the
weighed basket
B - Check nut to block the weighed
basket
C - Door lock rod
A - Nut to adjust the height of the
Do not move the nut "A" from the fixed position, since it has been set-up directly
by
weighed basket
B - Check nut to block the weighed
basket
C - Door lock rod
