Technical Manual
NAM-CLEAR-MT-EN-A
Security Booth
ClearLock
TECHNICAL MANUAL
Rev. A
Security Booth
The information contained in this document is the property of Automatic Systems
and is confidential. The recipient shall refrain from using it for any purpose other
than for the use of the products or the execution of the project to which it refers
and from communicating it to third parties without prior written agreement from
Automatic Systems. The document is subject to change without notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ClearLock and is the answer not in the manual?

Questions and answers

Summary of Contents for Automatic Systems ClearLock

  • Page 1 ClearLock TECHNICAL MANUAL Rev. A The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual than for the use of the products or the execution of the project to which it refers...
  • Page 2 2011-06-28 MLB + JB First version The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual than for the use of the products or the execution of the project to which it refers...
  • Page 3: Table Of Contents

    9. WIRING DIAGRAM ............................64 10. TERMINAL AND INPUT/OUTPUT ALLOCATION ..................65 The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual...
  • Page 4: Safety Warnings

    Any modifications to the parameters must be performed by experienced and qualified personnel. Automatic Systems is in no way responsible for any modifications made to the equipment. (Note: the Security Booth is factory configured in “minimal risk” mode for its users.) The information contained in this document is the property of Automatic Systems and is confidential.
  • Page 5: Description

    Lifting eye bolts Metal detector (optional) The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual than for the use of the products or the execution of the project to which it refers...
  • Page 6 (optional) Secured area Door closed detector The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual than for the use of the products or the execution of the project to which it refers...
  • Page 7: Installation

    Toweling paper  Masking tape The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual than for the use of the products or the execution of the project to which it refers...
  • Page 8: Packing List

    1, 6a, 12b M5 Lock washer 1, 6a, 12b The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual than for the use of the products or the execution of the project to which it refers...
  • Page 9 Display for volumetric single-presence detection configuration (optional) The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual than for the use of the products or the execution of the project to which it refers...
  • Page 10 Keys to manually lock the exterior obstacle (optional) 4 lifting eye bolts The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual...
  • Page 11: Equipment Assembly (If Delivered Unassembled)

    Support Support Support The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual than for the use of the products or the execution of the project to which it refers...
  • Page 12: Canopy

    2. Remove the screws (32) from the uprights (2, 3, 4, 5) and remove the rings (33). The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other...
  • Page 13 5. Install the covers only after running the electric cables (see section 3.7). The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual...
  • Page 14: Side Glass Panels

    Note: Apply the silicone. Allow 24 hours to dry before using the booth. Clean any silicone residue once dried. The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other...
  • Page 15: Mobile Obstacles

    Rack 5. Repeat the previous steps for the second door. The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual than for the use of the products or the execution of the project to which it refers...
  • Page 16: Ceiling Mount

    3. Fasten the ceiling mount (7) to the canopy braces with the screws (39). The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other...
  • Page 17: Inside Column

    5. Fasten the cover (12a) to the column (12b) with the screws (40). Run the cable through the hole in the ceiling The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual...
  • Page 18: Metal Detector (Optional)

    Cable through-hole M6 x 30 (4) M8 x 16 (2) The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual than for the use of the products or the execution of the project to which it refers...
  • Page 19: Equipment Installation (Assembled)

    The work must also be validated by a professionally qualified engineer. Automatic Systems cannot be held responsible for any accident or damage caused to the equipment due to improper floor attachment.
  • Page 20: Electrical Connections

    Connect both parts of the connector (MM02) to link the canopy components (lights, optional detectors, etc.) to the electronic board. The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual...
  • Page 21  Configure the device as indicated in section 5.13. Ground leads Attach the yellow/green leads between the metal components. The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual...
  • Page 22: External Booth Connections

     Fasten the intercom front plate to the upright. The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual...
  • Page 23 - Connect the power cable to case VB4313 (picture). Remove the hygroscopic salt pouches, if present. The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual...
  • Page 24: Start-Up

    7. Ensure the entry door remains locked after the key is turned in the outer lock. The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other...
  • Page 25: Operation

    Left object? (optional) Object removed by operator The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual than for the use of the products or the execution of the project to which it refers...
  • Page 26: Passage Authorization

    Door support Door closed detectors The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual than for the use of the products or the execution of the project to which it refers...
  • Page 27: Obstacle Locking And Unlocking

    WARNING: Safety photocells are not operational during the booth initialization cycle (i.e., when the booth is powered on). The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other...
  • Page 28: Ncd² Control Console

    4.8. NCD² control console The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual than for the use of the products or the execution of the project to which it refers...
  • Page 29: Console Description

    EMERG key switch to the ON B position RESET  The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual than for the use of the products or the execution of the project to which it refers...
  • Page 30 * Note: On slave consoles, only buttons 1, 2, 3 and 4 are operational. The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other...
  • Page 31: Console Parameter Programming

    5=> U.(S) OUT be modified. 6=> D.OP The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual than for the use of the products or the execution of the project to which it refers...
  • Page 32 6 => D.OP (Function not available.) The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual than for the use of the products or the execution of the project to which it refers...
  • Page 33: Alarm Messages

    TIME 4.8.3. Alarm messages  See section 5.2. The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual than for the use of the products or the execution of the project to which it refers...
  • Page 34: Obstacle Initialization

    Turn the SYSTEM key switch to the ON position to exit the READ PATH menu. The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other...
  • Page 35 Turn the SYSTEM key switch to the ON position to exit the MOTOR PARAMETER menu. The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other...
  • Page 36: Pictogram

    * Booths with a Ø of 58.5 in (1485 mm) are equipped with 2 sets of heating resistors and fans. The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other...
  • Page 37: Maintenance

    Verify that the mobile obstacles are aligned with the side panels in both the closed and open positions. The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other...
  • Page 38 Ensure all nuts and bolts of mobile obstacles supports are properly tightened. The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual...
  • Page 39 Left object detector (optional); Emergency stop (optional); Intercom (optional). The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual than for the use of the products or the execution of the project to which it refers...
  • Page 40: Problems And Troubleshooting (Alarms)

    The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual than for the use of the products or the execution of the project to which it refers...
  • Page 41 Obstacle movement is Clean the track (see section 5.1). hindered. The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual than for the use of the products or the execution of the project to which it refers...
  • Page 42 VB1290 and VB3406 (see wiring diagram). activated) does not VB1290 is operational. The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual...
  • Page 43 The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual than for the use of the products or the execution of the project to which it refers...
  • Page 44: Recommended Tightening Torques

    Stopper Position detector Detector bracket The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual than for the use of the products or the execution of the project to which it refers...
  • Page 45: Obstacle Lock Adjustment

    Connect the photocells as specified on the wiring diagram. Position the jumpers as illustrated below: The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other...
  • Page 46: Adjustment Of The Presence Detector Located Inside The Booth

    Increasing the sensitivity increases the risk of false error messages due to obstacle movement. The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other...
  • Page 47: Ncd² Console Configuration

    Slave configuration. For parameter setting see section 4.8. The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual than for the use of the products or the execution of the project to which it refers...
  • Page 48: Single-Presence Detection Adjustment (Optional)

    LED lights up when more than one person is detected in the booth PL1 + LD11: RESET button + LED signal 800-mA fuse The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual...
  • Page 49 Note: Verifications and adjustments must be done while the doors are closed. TR potentiometers must only be slightly turned. The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other...
  • Page 50: Metal Detector Adjustment (Optional)

    Buzzer LD14-13 LD1-2-3-4 The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual than for the use of the products or the execution of the project to which it refers...
  • Page 51 SW1: Microprocessor reset (for test procedures). SW2: Password reset to value "123456". The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual...
  • Page 52: Programming

    Note: For each function set, the selected value must be confirmed by pressing the PROGR button before exiting the function menu. The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other...
  • Page 53 Ensure all booths are synchronized. Electric connections on connector M6 and DIP switch adjustment on DS1 as follows: The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other...
  • Page 54 Turn all the booths on. Adjust the Function 1 parameter on the master booth only. The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other...
  • Page 55 + minimum noise damping (i.e., false metal detection alarms due to noise). Note: For the ClearLock metal detector, the suggested value is 10. Note: The transmitter antenna (red marker) must be installed on the side of potential noise sources (e.g., X- ray device).
  • Page 56 The proper setting will generate minimum LED oscillations on the BL LED bar when the 2 antennas are slightly shaken. Note: When program 0 is used with the ClearLock metal detector (see Function 10), the value should be between 220 and 250.
  • Page 57 Four types of filters can be used, depending on the program used (see Function 10) and the electromagnetic noise in the metal detector environment. Note: Except in special conditions, filter 1 must be set to ON and filters 2, 3 and 4 to OFF for the ClearLock metal detector.
  • Page 58: Prolonged Stop / Disposal

    When the equipment is taken out of service, dispose of the components (metal, glass, electronic components, etc.) in the appropriate manner and in accordance with applicable legislation. The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other...
  • Page 59: Technical Specifications

    Impact resistance: IK09 (housing).  MCBF (Mean Cycles Before Failure): 2 million (with recommended maintenance). The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual...
  • Page 60: Dimensions

    7. DIMENSIONS The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual than for the use of the products or the execution of the project to which it refers...
  • Page 61: Implementation Drawings

    8. IMPLEMENTATION DRAWINGS The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual than for the use of the products or the execution of the project to which it refers...
  • Page 62 The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual than for the use of the products or the execution of the project to which it refers...
  • Page 63 The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual than for the use of the products or the execution of the project to which it refers...
  • Page 64: Wiring Diagram

    A L AR M +2 4V F REE The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual than for the use of the products or the execution of the project to which it refers...
  • Page 65: Terminal And Input/Output Allocation

    Opening button Red pictogram Green pictogram The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual than for the use of the products or the execution of the project to which it refers...
  • Page 66 NSA motor +24 VDC Obstacle lock The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual than for the use of the products or the execution of the project to which it refers...
  • Page 67 F3 + F4 Motor protection NCD² console protection The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual than for the use of the products or the execution of the project to which it refers...
  • Page 68 The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other Technical Manual than for the use of the products or the execution of the project to which it refers...
