Function Anomalies - Automatic Systems ClearLock 645 Technical Manual

6. FUNCTION ANOMALIES

ANOMALY
The external door opens and
closes constantly a voice message
asks to "Please put all metal
objects in the box"
The door does not close.
The door does not work properly.
The metal detector's alarm
goes off constantly.
The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using this information for any purpose other
than the use of the products or the execution of the project to which it refers and from communicating it to third parties without prior written agreement of Automatic Systems.
The document is subject to change without notice.
ClearLock 645
-TM-EN
1) Check and see if any dangerous or suspicious object has been
abandoned in the booth. Please do not do anything and ring the alarm.
If it is a different object remove it as follows:
1.1) Do a "Reset" on the serial console and press "Enter" on the digital
console.
1.2) Open the internal door using the exit button and remove the
object.
1.3) After the door closes repeat the procedure described in point 1.1.
2) After having verified that the booth is empty follow the procedure
described in point 1.1.
3) Should this problem arise immediately after or after a short period of
time please contact
1) Two people are in the booth at the same time:
1.1) Through the intercom ask one person to leave.
2) A person that weighs too much is inside the booth or an adult with a child:
2.1) Push "Enter" on the digital console and "Reset" on the serial
console if you want to allow the person/people to pass. If not use
the intercom and ask the person to leave.
3) The booth is empty:
3.1) Check the console's condition. See that the "block" function is not
active on both the serial console and the digital console.
4) The booth is empty and none of the above conditions apply. (1-2-3):
4.1) Push "Enter" on the digital console and "Reset" on the serial
console.
5) The photocell on the side of the passage is covered:
5.1) Remove the object in front of the photocell.
5.2) Clean the photocell's glass.
5.3) Turn off the photocell. If it is the external photocell push 10 on the
serial console or 11 for the internal door.
Press 7 for a second at the same time.
The booth is reset, but you must call
service.
6) Please contact Automatic
1) Verify the settings on the console.
2) Do a console "Reset" (only the serial console).
1) Make sure that there are no metal objects near the external door.
2) Make sure that there are no maintenance workers or equipment near
the booth.
3) On the serial console press "Control" to de-activate the metal detector
and call Automatic Systems
4) On the digital console it is possible to lower the metal detector's
sensitivity (call Automatic
POSSIBLE SOLUTIONS
Automatic Systems
assistance service.
Automatic
Systems assistance service.
assistance service.
Systems assistance service).
Systems assistance
p. 42 / 44
