Programming And Diagnostics - Automatic Systems ClearLock 645 Technical Manual

4. PROGRAMMING AND ANALYSIS
Testing for bad or broken booth components and changes to the parameters different from those set by the
factory, must be made with the "Power Console" software available on request from
The "Power Console" program has been created to manage the booth functions of the Single board type.
This program works only with a hardware key. Should you need one, please contact
technical assistance service.
This program communicates with the booth using a serial door on the PC through a RS232/RS485 converter.
In order to work the software needs the following kit:
• RS232/RS485 converter.
• converter cable DB9 female, DB9 male.
• interface cable converter/logic 8 prong plug.
• programming cable with button.
• hardware key.
The minimum required to install is:
• Windows 2000 Professional.
• RAM 128 Mb.
• 100 Mb of free space on the hard disk.
Installing the "Power Console" program.
1) Click on "hdd32.exe" and choose typical installation. This will install the driver for the hardware key.
2) Install "Power Console".
ATTENTION: If a system error called "ENCODER ERROR" appears on the input status screen,
while opening the program, this could mean that:
• The power supply of the motors is inverted.
• Counting of the encoder rotation stage is inverted.
• Some type of hindrance prevents the doors to move toward the closed position.
For instructions on how to use the "Power Console" software, you can request the handbook
by calling
For Metal Detector maintenance or to change the parameters set by
must request the operating manual or contact
The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using this information for any purpose other
than the use of the products or the execution of the project to which it refers and from communicating it to third parties without prior written agreement of Automatic Systems.
The document is subject to change without notice.
ClearLock 645
-TM-EN
Automatic Systems technical assistance service.
Automatic
Automatic
Automatic
Automatic Systems assistance service.
Systems.
Systems
Systems you
p. 29 / 44
