2.8. Components list table 04
Rep. Particulars
1 Unmarked panels
2 Push button panel
3 Push button panel without intercom
4 Accident prevention photocells
5 Magnets
2.9. Components list table 05
Rep. Particulars
1 Nylon bolt M16 H15
2 Assembled door
3 Door's rubber side non active
4 Door's lower arm attachment
5 Door's lower arm attachment parts
6 CE complete push button panel
7 Basket's bubble floor
8A Glass basket wall
8B Unmarked basket wall
9 Phenol basket panel
10 Basket support shaft
11 Basket iron stanchion
12 Basket side CE iron stanchion
13 Door attachment screw
14 Screw M
15A Basket side glass wall CE
15B Unmarked basket wall side CE
