2.11. Components list table 06

Rep. Particulars
1 Basket support shaft
2 Top hub spacer ring
3 Internal cabin attachment plate
4 Top hub spacer ring
5 Basket ceiling
6 Carrier wheel pin
7 Carrier wheel
8 Carrier
9 Unblocking door spring
10 Electromagnet stabilizer
11 Internal cabin attachment plate
12 Pin parts to move carrier
13 Motor reducer connecting rod parts
14 Proximity Sensor
15 Encoder
16 Motor
17 Reducer
18 Motor reducer group
19 Proximity small reading square
20 Loading Cell
21 Motor reducer support
22 Magnet attachment plate
23 Small reading square attachment for electromagnet
24 Light
25 Light bulb
26 Cam.
The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using this information for any purpose other
than the use of the products or the execution of the project to which it refers and from communicating it to third parties without prior written agreement of Automatic Systems.
The document is subject to change without notice.
ClearLock 645
-TM-EN
Qty. Code
1 4401957
1 4302624
1 4402588
1 4302623
1 440719164
4 4302531
4 504117100
2 440818794R2
2 4402653
2 5105867
1 4402587
2 2209307
2 2209308
2 5092PNO
2 5206032
2 5108258
2 5008150
2 5108259
2 350844394
1 509T500
1 350818394R1
2 350818894
2 350818194
2 5801285
1 50912V10W
2 430667964R3
