Making the Connections

Connecting your cable modem is simple. Typical connections are
shown below.
Coaxial
cable
CAUTION
Locate the modem so that there is one inch of free
space between its top and sides and any other
device or the wall. This free space will ensure
proper air circulation. Do not block the vents in
any way. Failure to allow proper air circulation can
result in serious damage to the cable modem.
Do not place any items on top of the modem while
it is powered up.
Do not place the modem near a heating or air
conditioning duct, in direct sunlight, or in a
location susceptible to drastic temperature changes.
Installing Your Cable Modem
Power
adapter
USB cable
(Do not connect
until after you
install the driver)
7
