MPS EVHR2000-S-00A Quick Start Manual

The Future of Analog IC Technology
DESCRIPTION
The EVHR2000-S-00A is an evaluation board
for the HR2000. The HR2000 is a fluorescent
lamp ballast controller with PFC function and
high voltage half-bridge driver. Only 16pin is
used to offer cost effective solutions with
minimized external components.
The EVHR2000DS-00A is designed to drive
16W fluorescent lamp. With the simple and
sufficient on-time control APFC, the demo
board provides 400V DC bus voltage for ballast
and clean load for Grid. The power factor is
greater than 0.9 in all input voltage range. The
over-voltage and over-current protection of PFC
stage are integrated to ensure the safety.
The half-bridge ballast controller directly drives
two MOSFETs to control the fluorescent lamp.
The preheat and ignition time are programmed
to proper level to meets the characteristics of
fluorescent lamp. The over-voltage, over-
current, capacitive-mode, and end-of-life (EOL)
protection are all integrated.
The EVHR2000DS-00A meets EN55015 EMI
standard. And THD meets IEC61000-3-2 Class
C standard.
ELECTRICAL SPECIFICATION
Parameter Symbol
Input Voltage Vin
AC Line Frequency f
LINE
Lamp Voltage V
Lamp Current I
lamp
Lamp Power P
Preheat Current I
pre
Preheat time t
Pre
Open circuit voltage Voc
Burning frequency f
run
Efficiency η
Power Factor PF
EVHR2000-S-00A Rev.1.01
5/27/2013 MPS Proprietary Information. Patent Protected. Unauthorized Photocopy and Duplication Prohibited.
Value Units
198-264 VAC
50
55 Vrms
lamp
0.29
16
lamp
0.18-0.3
674
300 Vrms
40-50
>80
>90
www.MonolithicPower.com
© 2013 MPS. All Rights Reserved.
EVHR2000-S-00A
Fluorescent Lamp HB Driver with PFC
Features
PFC PART
•
Only four pins realize PFC function.
•
Ton control.
•
Boundary Conduction Mode operation.
•
Less peripheral components.
•
Over voltage and over current protection.
HALF-BRIDGE PART
•
600V bootstrap half-bridge driver.
•
Programmable preheat current.
•
Programmable preheat time.
•
Programmable ignition time.
•
Single ignition attempt.
•
Over voltage protection.
•
Over current protection.
•
End-Of-Life protection
•
Capacitive mode protection.
•
Minimized external components.
•
Over temperature protection
APPLICATIONS
•
Tube fluorescent lamp ballast
•
Compact fluorescent lamp ballast
All MPS parts are lead-free and adhere to the RoHS directive. For MPS green
status, please visit MPS website under Quality Assurance.
"MPS" and "The Future of Analog IC Technology", are Registered
Trademarks of Monolithic Power Systems, Inc.
Warning: Although this board is designed to satisfy safety
requirements, the engineering prototype has not been agency
approved. Therefore, all testing should be performed using an
Hz
isolation transformer to provide the AC input to the prototype
board.
A
W
A
ms
kHz
%
%
