Unpack and Organize
The table below lists the parts and components needed to retrofit a Sensor rack up to a
Sensor+ rack with a CEM+. Each part is listed to reflect the different quantities for the
different kits and types of racks.
1
Unpack and Organize
Parts/Components
ETC Part Number
CEM+ Backplane Bracket
7150A3002
CEM+ Backplane PCB Assy
7150B5003
CEM+ Backplane Label
7150A4005
Stand-off (4-40x.375 M-F 3/16-HX AL)
HW9322
CEM+ Backplane Short Shield
7150A3007
Screw (4-40X1/4 SEMS PhPHMS)
HW183
CEM+ Sensor Rack Retrofit Manual (this manual)
7150M2300
Backplane Screw (8-32X3/8 PhPHMS)
HW377
CEM+ Backplane 1/8" #8 screw spacer
HW9343
Wire tie - 4"
HW7121
Tie-mount (sticky-back)
HW741
Ethernet Termination Kit
4101A2003
CAT5 Cable RJ45/RJ45 UTP 1FT
N4036
Sensor+ Beacon (Blue LED) PCB Assy
7050B5109
Beacon PCB Screw (6-32X3/8 PhPHMS)
HW222
Sensor+ Beacon Door Acylic
7051A4116
Terminal Block 8F Plug Screw
J3407
CEM+ UPGRADE 16-PIN Power Cable
7150B7002
PCB Upgrade 16-Pin Power
7150B4009A
CEM+ Lower Ribbon Card Assy
7150B5006
CEM+ Upper Ribbon Card Assy
7150B5007
Sensor+ Door Label
7151A4001
Heat shrink - 4.5" x 1.5" dia.
W682
Heat shrink - 6" x 3/16" dia.
W606
1 1 1
1 1 1
1 1 1
6 6 6
1 1 1
8 8 8
1 1 1
2 2 2
2 2 2
8 8 10
4 4 4
1 1 1
1 1 1
1 1 1
2 2 2
1 1 1
2 2 2
1 1 1
1 1 1
1 1 1
1
1 1 1
1 1 1
1 1 1
1
1
1
6
1
8
1
2
2
14
4
1
1
1
2
1
2
1
1
2
2
1
1
1
3
