Remove the anchor assembly. See Figure 11.
Use a 5/32-inch Allen key to remove the socket-head set
screw. Discard the set screw. See Figure 12.
Step 8
Step 9
Disassembling the Loadbuster Loadbreak Tool
Figure 11. Remove the retaining ring and anchor assembly.
Figure 12. Remove and discard the set screw.
Retaining ring
Anchor
assembly
Allen key in set screw
S&C Instruction Sheet 811-510
Anchor
assembly
9
