S&C Loadbuster Instruction Sheet page 10

Disassembling the Loadbuster Loadbreak Tool
Step 10
Withdraw the stationary contact assembly from inside the
inner tube. See Figure 13.
Step 11
Remove the chassis cover by slightly prying the cover
equally on both sides and sliding off the chassis. See
Figure 14.
10
S&C Instruction Sheet 811-510
Stationary contact
assembly
Figure 13. Remove the stationary contact.
Pull out using
both hands
Figure 14. Remove the chassis cover.
Inner tube
Chassis cover
