3.3.1 Minimum Space Requirements to Transport the Machine and Turn Hallway
Corners
The following table represents the minimum width that is necessary to turn
hallway corners and transport the machine to its final installation site.
Equipment
Main Unit
Main Unit
(When the Operator
Panel Is Fully Extended)
POD Deck Lite-A1
Paper Deck Unit-A1
Multi Drawer Paper
Deck-A1
Document Insertion
Unit-H1
Professional Puncher-C1
Professional Puncher
Integration Unit-B1
Paper Folding Unit-G1
Staple Finisher-A1
Booklet Finisher-A1
Version 1 imageRUNNER ADVANCE C9075S PRO Customer Expectations Document
Dimensions When Transporting
(Depth x Width)
36 3/4" x 27 1/8"
(932 mm x 689 mm)
36 3/4" x 50 1/5"
(932 mm x 1,275 mm)
24 1/2" x 23 5/8"
(621 mm x 601 mm)
23" x 12 3/4"
(583 mm x 323 mm)
37 3/8" x 31 3/8"
(950 mm x 797 mm)
31 1/4" x 26 1/8"
(793 mm x 662 mm)
31 1/4" x 12"
(792 mm x 305 mm)
31 1/4" x 9 7/8"
(792 mm x 250 mm)
31 1/4" x 13 1/4"
(793 mm x 336 mm)
30 1/8" x 25 3/4"
(765 mm x 654 mm)
30 1/4" x 30 1/8"
(767 mm x 765 mm)
Minimum Corridor Width
Required
65 3/8"
(1,659 mm)
78 7/8"
(2,004 mm)
53 3/4"
(1,365 mm)
53 3/4"
(1,365 mm)
68 1/2"
(1,740 mm)
62 5/8"
(1,589 mm)
53 1/8"
(1,349 mm)
52 3/8"
(1,331 mm)
53 5/8"
(1,361 mm)
59 3/8"
(1,507 mm)
62 3/8"
(1,583 mm)
