USE, INSTALLATION AND MAINTENANCE
INSTRUCTIONS FOR BUILT-IN HOT PLATES
Dear Customer
Thank you for purchasing a Blanco Cooktop.
Before we continue telling you about this cooktop, we cordially invite you to become part of the Blanco family by
subscribing to ongoing information and invitations. Please visit our website where you can subscribe and request
such things as invitations to future cooking classes and gourmet recipes. Go to www.meaappliances.com.au and
fill in the subscription details.
You will find that the clean lines and modern look of your Blanco Cooktop blends perfectly with your kitchen décor.
It is easy to use and performs to a high standard.
Blanco also makes a range of products that will enhance your kitchen such as ovens, rangehoods, dishwashers,
microwaves, sinks and taps.
There are models to complement your new Blanco Cooktop.
Of course we make every effort to ensure that our products meet all your requirements, and our Customer
Relations department is at your disposal, to answer your questions and to listen to all your suggestions (see back
cover of manual).
Please complete the warranty section of this manual and keep your receipt as proof of purchase. Retain all
documents relating to the purchase of this products.
Blanco is committed to providing increasingly efficient products that are easy to use, respect the environment and
are attractive and reliable.
BLANCO
We ask that you carefully read the instructions within this booklet to enable you to abtain quality results from the outset.
The appliance must be installed only by an authorised person in compliance with the instructions provided. The manufacturer
declines all responsability for improper installation which may harm persons and animals and damage property.
The appliance must be used for the purpose for which it was expressly designed. Any other use (eg heating rooms) is considered to
be improper and consequently dangerous. The manufacturer declines all responsability for damage resulting from improper and
irresponsible use.
The manufacturer shall not be held responsible for any inaccuracies in this handbook due to printing or transcription errors. The
designs in the figures are purely indicative.
The manufacturer also reserves the right to make any modifications to the products as may be considered necessary, useful or in the
interests of the user, without jeopardizing the main functional and safety features on the products themselves.
If your cooktop requires service, please contact your local customer service centre or your nearest Blanco agent listed at the back of
this booklet.
MODELS: PI5V
COD. 04071GGB - 23.12.2009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PI5V and is the answer not in the manual?

Questions and answers

Summary of Contents for Blanco PI5V

  • Page 1 If your cooktop requires service, please contact your local customer service centre or your nearest Blanco agent listed at the back of this booklet.
  • Page 2 DESCRIPTION OF THE HOT PLATES Natural Propane 1 Ultra rapid gas burner 12.6 MJ/h 11.16 MJ/h 2 Rapid gas burner 10.8 MJ/h 10.8 MJ/h 3 Front semirapid gas burner 6.3 MJ/h 6.3 MJ/h 4 Back semirapid gas burner 6.3 MJ/h 6.3 MJ/h 5 Auxiliary gas burner 3.6 MJ/h...
  • Page 3 1) BURNERS - Always place a lid on the pans. - Use only pan with a flat bottom. A diagram is screen-printed above each knob on the front panel. This diagram indicates to which Power ratings burner the knob in question corresponds. After Pan Ø...
  • Page 4 Notes: use of a gas cooking appliance produces heat and moisture in the room in which it is installed. The room must therefore be well ventilated by keeping the natural air vents clear (fig. 3) and by activating the mechanical aeration device (suction hood or electric fan fig. 4 and fig. 5). Intensive and lengthy use of the appliance may require additional ventilation.
  • Page 5 CLEANING IMPORTANT: - Check that enamelled burner cap “C” (fig. 6) always disconnect the appliance from the gas have correctly positioned on the burner head. and electricity mains before carrying out any It must be steady. cleaning operation. - The exact position of the pan support is established by the rounded corners, which should be set towards the side edge of the 2) HOT PLATE...
  • Page 6: Installation

    INSTALLATION TECHNICAL INFORMATION 4) FIXING THE HOT PLATE FOR THE INSTALLER The hot plate has a special seal which prevents liquid from getting into the cabinet. Strictly comply Installation, adjustments of controls and with the following instructions in order to correctly maintenance must only be carried out by a apply this seal: qualified engineer.
  • Page 7 INSTALLATION...
  • Page 8 INSTALLATION “FILOTOP” HOT PLATE INSTALLATION FIG. 10...
  • Page 9: Electrical Connection

    INSTALLATION 5) GAS CONNECTION The transition piece on the supply side of the regulator must be provided by the installer. The gas connection is located in the rear and on the Liquified Petroleum Gas underside of the appliance 100 mm from the right In a Propane Gas installation the gas regulation is hand side.
  • Page 10 ADJUSTMENTS 7) TAPS Always disconnect the appliance from the electricity main before making any adjustments. Our taps are suitable for all gas, they are male All seals must be replaced by the technician at conical type. the end of any adjustments or regulations. “Reduced rate”...
  • Page 11 PROPANE GAS CONVERSION PROCEDURE Appliance models: Gas stainless steel hotplate Appliance models: Gas stainless steel hotplate models: models: PI5V 5 Burners PI5V 5 Burners 1. Remove each burner cap and burner skirt. 1. Remove each burner cap and burner skirt.
  • Page 12: Replacing The Injectors

    CONVERSIONS 10) REPLACING THE INJECTORS seals on the regulating or pre-regulating devices. The envelope with the injectors and the labels can The burners can be adapted to different types of be included in the kit, or at disposal to the gas by mounting injectors suited to the type of gas authorized customer Service Centre.
  • Page 13 SERVICING Always disconnect the appliance from the Greasing the taps (see fig. 20) electricity and gas mains before proceeding If a tap becomes stiff to operate, it must be with any servicing operation. immediately greased in compliance with the following instructions: 11) REPLACING HOT PLATE PARTS - remove the tap.
  • Page 14 SERVICING CABLE TYPES AND SECTIONS TYPE OF SINGLE - PHASE TYPE OF POWER SUPPLY HOT PLATE CABLE Gas hot plate H05 RR - F Section 3 x 0.75 mm ATTENTION!!! If the power supply cable is replaced, the installer should leave the ground wire longer than the phase conductors (fig.
  • Page 15: Technical Assistance And Spare Parts
