USE, INSTALLATION AND MAINTENANCE
INSTRUCTIONS FOR BUILT-IN HOT PLATES
Dear Customer
Thank you for purchasing a Blanco Cooktop.
Before we continue telling you about this cooktop, we cordially invite you to become part of the Blanco family by
subscribing to ongoing information and invitations. Please visit our website where you can subscribe and request
such things as invitations to future cooking classes and gourmet recipes. Go to www.meaappliances.com.au and
fill in the subscription details.
You will find that the clean lines and modern look of your Blanco Cooktop blends perfectly with your kitchen décor.
It is easy to use and performs to a high standard.
Blanco also makes a range of products that will enhance your kitchen such as ovens, rangehoods, dishwashers,
microwaves, sinks and taps.
There are models to complement your new Blanco Cooktop.
Of course we make every effort to ensure that our products meet all your requirements, and our Customer
Relations department is at your disposal, to answer your questions and to listen to all your suggestions (see back
cover of manual).
Please complete the warranty section of this manual and keep your receipt as proof of purchase. Retain all
documents relating to the purchase of this products.
Blanco is committed to providing increasingly efficient products that are easy to use, respect the environment and
are attractive and reliable.
BLANCO
90 CM, 5 BURNER GAS COOKTOP ( FRONT CONTROL )
We ask that you carefully read the instructions within this booklet to enable you to abtain quality results from the outset.
The appliance must be installed only by an authorised person in compliance with the instructions provided. The manufacturer
declines all responsability for improper installation which may harm persons and animals and damage property.
The appliance must be used for the purpose for which it was expressly designed. Any other use (eg heating rooms) is considered to
be improper and consequently dangerous. The manufacturer declines all responsability for damage resulting from improper and
irresponsible use.
The manufacturer shall not be held responsible for any inaccuracies in this handbook due to printing or transcription errors. The
designs in the figures are purely indicative.
The manufacturer also reserves the right to make any modifications to the products as may be considered necessary, useful or in
the interests of the user, without jeopardizing the main functional and safety features on the products themselves.
If your cooktop requires service, please contact your local customer service centre or your nearest Blanco agent listed at the back of
this booklet.
MODEL: BCGR95WX
COD. 04010BLA - 23.06.2004

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BCGR95WX and is the answer not in the manual?

Questions and answers

Summary of Contents for Blanco BCGR95WX

  • Page 1 If your cooktop requires service, please contact your local customer service centre or your nearest Blanco agent listed at the back of this booklet.
  • Page 2 DESCRIPTION OF THE HOT PLATES Natural U-LPG 1 Ultra rapid burner of 11.9 MJ/h 11.9 MJ/h 2 Rapid gas burner of 10.4 MJ/h 10.8 MJ/h 3 Semi rapid gas burner of 6.3 MJ/h 6.3 MJ/h 4 Auxiliary gas burner of 3.6 MJ/h 3.6 MJ/h 5 Enamelled steel pan support 2F right...
  • Page 3 gas consumption: 1) BURNERS - Use adequate pans for each burner (consult the A diagram is screen-printed above each knob on the front following table and fig. 2). panel. This diagram indicates to which burner the knob in - When the pan comes to the boil, set the knob to the question corresponds.
  • Page 4 Notes: Use of a gas cooking appliance produces heat and moisture in the room in which it is installed. The room must therefore be well ventilated by keeping the natural air vents clear (fig. 3) and by activating the mechanical aeration device (suction hood or electric fan fig. 4 and fig. 5). Intensive and lengthy use of the appliance may require additional ventilation.
  • Page 5 CLEANING IMPORTANT: Always disconnect the appliance from the gas and electricity mains before carrying out any cleaning operation. 2) HOT PLATE Periodically wash the hot plate, the enamelled steel pan support, the enamelled burner caps “C” and the burner heads “M” (see fig. 6) with lukewarm soapy water. Following this, all parts should be thoroughly rinsed and dried.
  • Page 6: Installation

    INSTALLATION Never leave the packacing materials (cardboard, TECHNICAL INFORMATION FOR THE INSTALLER bags, polystyrene foam, nails, etc.) within children’s reach since they could become potential sources of This appliance shall be installed only by authorised danger. personnel and in accordance with the manufacturer’s The measurements of the opening made in the top of the installation instructions, local gas fitting regulations, modular cabinet and into which the hot plate will be installed are...
  • Page 7 INSTALLATION turn the screw “F” until the bracket “S” stick on the 4) FIXING THE COOKTOP top (fig. 9). The hot plate has a special seal which prevents liquid - The prospective walls (left or right) that exceed the from infiltrating into the cabinet. Strictly comply with working table in height must be at a minimum the following instructions in order to correctly apply distance from the cutting as mentioned both in the...
  • Page 8: Gas Connection

    INSTALLATION The transition piece on the supply side of the 5) GAS CONNECTION regulator must be provided by the installer. The gas connection is located in the rear and on the Liquified Petroleum Gas underside of the appliance 265 mm from the right In a U-LPG installation the gas regulation is made hand side.
  • Page 9 ADJUSTMENTS Always disconnect the appliance from the 7) TAPS electricity main before making any adjustments. Our taps are suitable for all the gas, they are male All seals must be replaced by the technician at conical type at one way. the end of any adjustments or regulations.
  • Page 10 Adjust the gas pressure to 1.00 kPa with the wok burner operating on high flame. BCGR95WX 5 Burners 10. Remove the control knob, with a thin shaft blade screwdriver inserted on the left side of the Remove each burner cap and burner skirt.
  • Page 11 7. Fit the U-LPG test point inlet fitting supplied in the conversion kit. BCGR95WX 5 Burners 8. Connect the gas supply to the inlet fitting. 9. Check for gas leaks. Do not use a naked flame 1. Remove each burner cap and burner skirt.
  • Page 12 CONVERSIONS BURNER ARRANGEMENT ON THE HOT PLATE TABLE 1 NORMAL INJECTOR NOMINAL HEAT BURNERS PRESSURE DIAMETER INPUT (MJ/h) N° DESCRIPTION (kPa) (1/100 mm) MAX. U-LPG 2.75 11.9 ULTRA RAPID NATURAL 1.00 11.9 U-LPG 2.75 10.8 RAPID NATURAL 1.00 10.4 U-LPG 2.75 SEMI RAPID NATURAL...
  • Page 13: Components Replacement

    SERVICING WARNING: Greasing the taps (see fig. 20 - 21) Servicing should be carried out only by If a tap becomes stiff to operate, it must be authorised personnel. immediately greased in compliance with the following instructions: 10) COMPONENTS REPLACEMENT - Remove the tap.
  • Page 14 SERVICING CABLE TYPES AND SECTIONS TYPE OF TYPE OF SINGLE - PHASE HOT PLATE CABLE POWER SUPPLY Gas hot plate H05 RR - F Section 3 X 0.75 mm ATTENTION!!! If the power supply cable is replaced, the installer should leave the ground wire longer than the phase conductors (fig.
