- Page 1 Instructions for the Use and Care and Installation of BIC603T BIC604T BIC75T Induction Cooktop...
- Page 2 It is easy to use and performs to a high standard. Blanco also makes a range of products that will enhance your kitchen – such as cooktops, ovens, dishwashers, microwaves, sinks and taps. There are models to complement your new Blanco rangehood.
- Page 3 Fig.1 - Glass-ceramic cooker top. - Pan with ferromagnetic base. - Magnetic field. - Archimedean spiral coil. - Current. - Electric circuit. - 3 -...
- Page 4 Fig.2 Fig.2B 220-240 V~ H05V2V2-F 220-240 V2~ H05V2V2-F - 4 -...
- Page 5 Fig.3 Fig.3B 220-240V 1N ~ H05V2V2-F 3G 220-240V 2~ H05V2V2-F 3G 380-415V 2N~ H05V2V2-F 4G - 5 -...
- Page 6 Fig.4 - 6 -...
- Page 7 Fig.5 5 8 0 - 7 7 + 2 0 M i n 5 6 0 - 7 5 M i n Fig.6 - 7 -...
- Page 8 - 40 % Fig.7 Fig.8 50 mm 4 mm 25 mm 80 mm 500 x 10 Fig.9 - 8 -...
- Page 9 50 mm 4 mm 40 mm 500 x 10 500 x 50 Fig.10 - 9 -...
-
Page 10: Safety Warnings
SAFETY WARNINGS • Read the following carefully to avoid an electric shock or fire. • It is most important that this instruction book should be retained with the appliance for future reference. • Should the appliance be sold or transferred, always ensure that the book is left with the appliance in order that the new owner can get to know the functions of the appliance and the relevant warnings. -
Page 11: Installation Instructions
Caution: if you are using a pan with a diameter which is more than 40% smaller than the printing marked on the glass, the cooking zone may not be activated. 1.3 Cooking vessels (Fig.7A): Cooking by induction uses magnetism to generate heat. The vessels must therefore contain iron. Check if the vessel material is magnetic using a magnet. -
Page 12: Use And Maintenance
Important: if there is an oven under the induction hob it is advisable for it to have a cooling fan. Do not use the induction hob while PYROLITIC cleaning is in process. Warning: to allow the circulation of as much fresh air as necessary, there must be at least 40 mm between the induction hob module and any appliance installed under it (Fig.10B). - Page 13 - Use “+” or “-” buttons to regulate the power level. - By selecting the “-” key the power level goes directly to 9. - If after about 10 seconds no operation is carried out, display shade goes back to the initial one. The hob will continue its normal cooking.
- Page 14 3/4 burner version: - If the decimal point “•” appears on the displays, it means that timer is active. - During cooking the time set previously with the timer is not displayed. - In order to view the time remaining on the Timer of a cooking zone, select that cooking zone and then press the “+”...
- Page 15 - The Booster can be activated simultaneously on all the enabled zones. - The Booster function will be active for about 5 minutes, after which cooking will continue at level 9. - In order to stop this function, select the concerned cooking zone and the “-” key until you reach the desired level.
- Page 16 • Error codes: Error code: Description: Possible causes: Error recovery: The cooking zone can be It’s not an error, the user is in A suitably pan must be placed on the configured if a static “C” is the service menu. relevant cooking zone.
- Page 20 Printed on recycled paper 3LIP0361...
