  • Page 1 BTL5-T1 _ _ -M _ _ _ _ -A/B/Y/Z-S103 User’s Guide english...
  • Page 2 www.balluff.com...

  • Page 3: Table Of Contents

    Starting up the system Operating notes Default settings Presettings 5.4.1 Station address 5.4.2 Bus termination 5.4.3 LED display for PROFIBUS encoder profile Technical data Accuracy Ambient conditions Supply voltage (external) Control signals Output Dimensions, weights Connection to the evaluation unit www.balluff.com english...
  • Page 4 BTL5-T1 _ _ -M _ _ _ _ -A/B/Y/Z-S103 Transducer – Rod Style Accessories Magnets Mounting nut Connectors and cables 7.3.1 Connector, freely configurable 7.3.2 Connector, preassembled 7.3.3 Connecting cable, preassembled 7.3.4 Bus termination resistance, freely configurable 7.3.5 Screw plugs Type code breakdown Appendix Converting units of length Part label english...

  • Page 5: Notes To The User

    – Electrical fast transients (burst) EN 61000-4-4 Severity level 3 Software – Surge GSD file via download on the Internet at www.balluff.com EN 61000-4-5 Severity level 2 or email to service@balluff.de. – Conducted interference induced by high-frequency fields EN 61000-4-6 Severity level 3 –...

  • Page 6: Safety

    The warnings used here contain various signal words and the specifications in the technical data is ensured only are structured as follows: when using original Balluff accessories. Use of any other SIGNAL WORD components will void the warranty. Hazard type and source...

  • Page 7: Construction And Function

    (rod). A magnet is moved Fig. 3-2: Distance between the magnets along the waveguide. This magnet is connected to the system part whose position is to be determined. The magnet defines the position to be measured on the waveguide. www.balluff.com english...

  • Page 8: Installation And Connection

    BTL5-T1 _ _ -M _ _ _ _ -A/B/Y/Z-S103 Transducer – Rod Style Installation and connection Installation guidelines Preparing for installation Installation note: We recommend using non- Non-magnetizable material magnetizable material to mount the transducer and magnet. Non-magnetizable material Horizontal assembly: For horizontal assembly with nominal lengths >...

  • Page 9: Installing The Transducer

    Slide element Magnet Spacer ring Fig. 4-7: Fixing of magnet An example of how to install the transducer with a supporting rod is shown in Fig. 4-8 on page 10. Fig. 4-5: Example 1, transducer installed with slide element www.balluff.com english...

  • Page 10: Shielding And Cable Routing

    BTL5-T1 _ _ -M _ _ _ _ -A/B/Y/Z-S103 Transducer – Rod Style Installation and connection (continued) The transfer rate depends on the length of the cable. In Magnet accordance with EN 50170, the values named in Tab. 4-2 (e.g. BTL-P-1028-15R) apply. Cable length Baud rate [kbit/s] <...

  • Page 11: Electrical Connection

    Master BKS-S105-R01 BKS-S103/GS103-CP-… # 125 Bus In Bus Out Bus In Bus Out Bus In Bus Out PROFIBUS-DP Interface PROFIBUS-DP Interface PROFIBUS-DP Interface BTL5-T1…-S103 BTL5-T1…-S103 BTL5-T1…-S103 +24 V BKS-S 48-15-CP-… Fig. 4-10: BTL5-T1…-S103 transducer with master, connection example www.balluff.com english...

  • Page 12: Startup

    BTL5-T1 _ _ -M _ _ _ _ -A/B/Y/Z-S103 Transducer – Rod Style Startup Starting up the system Presettings The station address can be configured through the DANGER Set_Slave_Address service. This service requires a class 2 DP master. The position measuring system’s GSD file is Uncontrolled system movement used for configuration.

  • Page 13: Station Address

    LED display for PROFIBUS encoder profile If multiple malfunctions are present at the same time, the malfunction with the highest priority is displayed. Detailed configuration instructions can be requested on the Internet at www.balluff.com via email at service@balluff.de. www.balluff.com english...

  • Page 14: Technical Data

    Nominal length 500 mm, magnet in the middle of the measuring range : Use in enclosed spaces and up to a height of 2000 m above sea level. Ambient conditions Individual specifications as per Balluff factory standard, resonant frequencies excluded Operating temperature −40°C…+85°C...

  • Page 15: Dimensions, Weights

    Rod wall thickness 2 mm Housing mounting M18×1.5 or 3/4"-16UNF via threads Tightening torque Max. 100 Nm Connection to the evaluation unit The maximum length of the entire field bus cable is 1200 m. Cable twisted in pairs, shielded see Fig. 4-10. www.balluff.com english...
  • Page 16 BTL5-T1 _ _ -M _ _ _ _ -A/B/Y/Z-S103 Transducer – Rod Style Accessories BTL-P-1013-4R, BTL-P-1013-4S, BTL-P-1012-4R, Accessories are not included in the scope of delivery and must be ordered separately. BTL-P-1014-2R: Weight: < 15 g Housing: Aluminum Magnets BTL-P-1013-4R Included in the scope of delivery for the BTL-P-1013-4R, BTL-P-1013-4S, BTL-P-1012-4R: Spacer: 8 mm, material: polyoxymethylene...
  • Page 17 BKS-S48-15-CP-05: cable length 5 m Ø 20 Fig. 7-7: Connector BKS-S48-15-CP-… Fig. 7-4: Connector BKS-S104-00 (socket) for BUS IN BKS-S105-00 Straight connector, freely configurable M12, 5-pin Cable feed-through (pinch ring PG 9) Fig. 7-5: Connector BKS-S105-00 (pin) for BUS OUT www.balluff.com english...
  • Page 18 BTL5-T1 _ _ -M _ _ _ _ -A/B/Y/Z-S103 Transducer – Rod Style Accessories (continued) 7.3.3 Connecting cable, preassembled 7.3.4 Bus termination resistance, freely configurable BKS-S103/GS103-CP-… BKS-S105-R01 Connecting cable, preassembled Bus termination resistance, freely configurable M12, 5-pin M12, 5-pin Various cable lengths can be ordered, e.g. Installed resistors BKS-S103/GS103-CP-05: cable length 5 m Fig.
  • Page 19 B = Metric mounting thread M18x1.5, O-ring, rod diameter 10.2 mm Y = 3/4”-16UNF thread, O-ring, rod diameter 10.2 mm Z = 3/4"-16UNF thread, O-ring, rod diameter 10.2 mm Electrical connection: S103 = 1 x 3-pin male 1 x 5-pin male 1 x 5-pin female www.balluff.com english...
  • Page 20 BTL5-T1 _ _ -M _ _ _ _ -A/B/Y/Z-S103 Transducer – Rod Style Appendix Converting units of length Part label 1 mm = 0.0393700787 inches inch 0.03937008 0.07874016 0.11811024 0.15748031 0.19685039 0.23622047 0.27559055 0.31496063 0.35433071 0.393700787 Tab. 9-1: Conversion table mm to inches Order code Type 1 inch = 25.4 mm Serial number Fig.
