- Page 1 JetCon 1100 / 1200 USB to Serial Converter series User’s Manual Version 1.0 www.korenix.com...
- Page 2 JetCon 1100 / JetCon 1200 User’s Manual Copyright Notice Copyright 2013 Korenix Technology Co., Ltd. All rights reserved. Reproduction in any form or by any means without permission is prohibited.
- Page 3 Declaration of CE This product has passed the CE certification for environmental specifications. Test conditions for passing included the equipment being operated within an industrial enclosure. In order to protect the product from being damaged by ESD (Electrostatic Discharge) and EMI leakage, we strongly recommend the use of CE-compliant industrial enclosure products.
-
Page 4: Table Of Contents
Software Driver Installation ................14 Appendix ....................17 Specification of JetCon 1101 / JetCon 1101i-5KV......... 17 Specification of JetCon 1102..............18 Specification of JetCon 1104..............19 Specification of JetCon 1201 /JetCon 1201i-3KV ......... 20 Revision History ..................23 About Korenix ..................24... -
Page 5: Introduction
1 Introduction Welcome to Korenix JetCon 1100 and JetCon 1200 USB to Serial Converter series. Following topics are covered in this chapter: 1.1 Overview 1.2 Major Features 1.3 Package Checklist 1.1 Overview The JetCon 1100 and JetCon 1200 series provides USB to serial communicate ability with RS-232 (JetCon 1100) and RS-422/ RS-485 (JetCon 1200) serial modes. -
Page 6: Package List
Note-1: those certifications are pending for special project request, please contact your sales widnow. 1.3 Package List Korenix JetCon 1100/ JetCon 1200 Series are shipped with following items: JetCon 1100 USB/ Serial RS-232 or JetCon 1200 USB/ Serial RS422/485 Converter One Mini-USB female to USB female cable ... -
Page 7: Hardware Installation
Panel Layout 2.2 Wiring to Serial Device and Host Computer Connectting USB interface Connecting RS-232 (JetCon 1100 series) Connecting RS-422 / RS-485 (JetCon 1200 series) Hardware Introduction This session will present different model with dimension and panel/bottom layout for the further install and configuration. - Page 8 JetCon 1101 / JetCon 1101i-5KV dimension is: 80 (H) x 42 (W) x 22 (D) / without DIN Rail Clip...
- Page 9 JetCon 1102 dimension is: 89mm (H) x 58.3mm (W) x 22mm (D) / without DIN Rail Clip...
- Page 10 JetCon 1104 dimension is: 89mm (H) x 62.6 mm (W) x 22 mm (D) w/o DIN Rail Clip...
- Page 11 JetCon 1201 / JetCon 1201i-3KV dimension is: 89mm (H) x 62.6 mm (W) x 22 mm (D) w/o DIN Rail Clip...
- Page 12 Deice Panel Introduction JetCon 1101 / JetCon 1101i-5KV USB to 1-port RS-232 Serial Converter JetCon 1102 USB to 2-port RS-232 Serial Converter...
-
Page 13: Wiring To Serial Device (Dce) And Host Computer (Dte)
JetCon 1201 / JetCon 1201i-3KV USB to 1-port RS-422/RS-485 Serial Converter Wiring to Serial Device (DCE) and Host Computer (DTE) The JetCon 1100 series and 1200 series support one Mini-USB interface with version 1.1/1.2 and 2.0, and the serial interface supports RS-232 for JetCon 1100 and RS-422/ RS-485 for JetCon 1200. - Page 14 Connecting RS-232 Interface The RS-232 interface presented in JetCon 1100 series. In the session 2.1 Hardware Introduction have introduced the model name and function description. So, the JetCon 1100 series support RS-232 interface from 1 port to 4 ports, and JetCon 1101i-5KV provides isolated design for medical application, all of JetCon 1100 supports 15KV Human Body mode ESD protection.
- Page 15 The following diagram shows the connections of RS-232 DTE-DTE device with hand-shaking, and DTE- DTE without hand-shaking mode (Null Modem). DB-9 DB-25 Signal Signal DB-25 DB-9 S.G. S.G. Null Modem Connection Above diagram shows the best wiring method with 3 wires straight cable connection between 2 DTE (Data Terminal Computer / Host Computer).
- Page 16 Connecting RS-422/ RS-485 Interface The RS-422/ RS-485 interface only presented in JetCon 1201 and JetCon 1201i-3KV. Both of model support RS-422 and RS-485 serial communication ability in 5-pin removable terminal block connector. The RS-422/ RS485 communication does not support flow control / hand-shaking;...
-
Page 17: Install The Usb /Serial Converter Onto Din Rail
RS-485 4-wire communication mode (Full Duplex Communication mode) The RS-485 multi-drop mode offers 32 nodes at same current loop bus, and it is recommended to enable 120ohm line terminator to obtain better data communication reliability in RS-485 bus. It is not necessary to add extra 120 ohm line terminator on each RS-485 node, just enable the DIP Switch-4 of line Terminator Resistor of 1 and last node of RS-485 bus for reliable current looping. -
Page 18: Software Driver Installation
Follow below steps to mount the converter onto standard DIN rail track. 1. Insert the bottom of the DIN-Rail clip into the DIN-Rail track from its low side. 2. Lightly push up Converter and press close to DIN-Rail clip, and make sure the upside clip is locked into the track. - Page 19 Perform install driver from specific location – CD-ROM. The path of driver is CD-ROM\product \Driver\, and under the folder there are several sub-folders for different operating systems. Above figure shows there is 4-port High Speed RS-232 device. Therefore, the computer system will request install driver 4 times for physical port-1 to port-4, and in the device manager of computer system will add new USB-Serial port with new logical COM port number as following figure.
- Page 20 The default serial communication parameters is 9600 bit rate/ per second, 8 data bits, no parity check, 1 stop bit and without flow control. It also supports advanced configuration for USB transfer size, latency time, time out setting for Read and Write. The USB transfer size default value is maximum size for receive and transmit.
-
Page 21: Appendix
Note:1. Install hadware system, and connect the USB cable to USB/Serial converter first. 2. Install drive – you can install driver through the device manger interface, or follow the hardware wizard to install each COM port. 3. The driver will install many times, if the converter supports multiple serial port function. -
Page 22: Specification Of Jetcon 1102
Transmit Buffer: 128Bytes FIFO Buffer Receive Buffer: 256Bytes Interface USB: Mini USB slave , B-Type Connector Serial: DB-9, Female USB:5 Meters Connection Distance RS-232 Serial: 15 Meters Length of Data bit: 7, 8 bits Serial Parameters Stop bit:1,2 Type of parity check: None, Even, Odd, Space, Mark Type of Flow Control: RTS/ CTS, XON/ XOFF Serial Signal TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND... -
Page 23: Specification Of Jetcon 1104
System performance USB 2.0 compatible with maximum 480Mbps data throughput Forwarding Rate RS-232 baud rate up to 921.6Kbps Transmit Buffer: 4KBytes FIFO Buffer Receive Buffer: 4KBytes Interface USB: Mini USB slave , B-Type Connector Serial: 2 x DB-9- Male USB:5 Meters Connection Distance RS-232 Serial: 15 Meters Length of Data bit: 7, 8 bits... -
Page 24: Specification Of Jetcon 1201 /Jetcon 1201I-3Kv
System performance USB 2.0 compatible with maximum 480Mbps data throughput Forwarding Rate RS-232 baud rate up to 921.6Kbps Transmit Buffer: 2KBytes FIFO Buffer Receive Buffer: 2KBytes Interface USB: Mini USB slave , B-Type Connector Serial: 4 x DB-9- Male USB:5 Meters Connection Distance RS-232 Serial: 15 Meters Length of Data bit: 7, 8 Bits... - Page 25 RS-422 / RS-485 baud rate up to 921.6Kbps Transmit Buffer: 128 Bytes FIFO Buffer Receive Buffer: 256 Bytes Interface USB: Mini USB slave , B-Type Connector Serial: DB-9, Female Cable for Serial Interface RS-422 / RS-485: Twisted Pair Cable. Select and Control by DIP Switch setting. Operating Mode Build-in 120ohm line terminator resistor and configured by DIP Switch.
-
Page 27: Revision History
Revision History Edition Date Modifications 25-Feb-2013 New editting 27-Feb,2013 Update with driver path. 12-Mar-2013 Modify RS-485 four-wire architecture and add some description for RS-485 and RS-422 wiring architecture. 15-Mar-2013 Update product specification with I-Testing’s suggestion: RX LED change to amber color Modify USB 2.0 compatible.. -
