- Page 1 495.06.283 HBO-TC65B INSTRUCTION MANUAL BUILT-IN ELECTRIC OVEN...
- Page 2 DEAR CUSTOMER, Caution!
-
Page 3: Table Of Contents
TABLE OF CONTENTS Safety instructions ......................4 Description of the appliance ..................... 8 Installation ......................... 10 Operation ........................... 12 Baking in the oven – practical hints ................19 Cleaning and maintenance ....................21 ........................26... -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS Warning: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning... - Page 5 SAFETY INSTRUCTIONS resistant to high temperatures. to overheating or boiling over. can scratch the surface, which could then result in the glass cracking. report the fault to the service centre to be repaired. observed. Do not allow anybody who is not familiar with the contents of this instruc- tion manual to operate the oven.
- Page 6 HOW TO SAVE ENERGY Using energy in a respon- sible way not only saves money but also helps the environment. So let’s save energy! And this is how you can do it: Do not uncover the pan too often (a watched pot never boils!). Do not open the oven door unnecessarily often.
- Page 7 DISPOSAL OF THE APPLIANCE UNPACKING During transportation, protec- tive packaging was used to ply be disposed of with normal protect the appliance against household waste, but should any damage. After unpack- be delivered to a collection and ing, please dispose of all recycling centre for electric and elements of packaging in a way that will not cause dam-...
-
Page 8: Description Of The Appliance
DESCRIPTION OF THE APPLIANCE Electronic Oven door handle Time Temperature Touch controls... - Page 9 SPECIFICATIONS OF THE APPLIANCE...
-
Page 10: Installation
INSTALLATION Installing the oven The kitchen area should be dry and aired When installing the oven, easy access to all control elements should be ensured. This is a Y–type design built–in oven, which means that its back wall and one side wall can be placed next to a high piece of furniture or a wall. - Page 11 INSTALLATION Electrical connection The oven is manufactured to work with a plug including a protection contact. A connection socket for electricity supply pin and may not be located above the cooker. After the cooker is positioned, it is necessary to make the connection socket accessible to the user.
-
Page 12: Operation
OPERATION Important! with display controlled by sensors Remove packaging, clean the interior of the oven. touch the glass above the sensor ustic signal will be heard, which was uid. Switch on the ventillation in the room or Using the control panel). open a window. - Page 13 OPERATION Using the control panel Touch controls Oven functions - Temperature selection - Light - Time setting - Fast heat-up - Programme selection - Defrosting - Setting selection - Turbo grill - Setting selection - Super grill - Child Lock - Barbecue grill - Stand by / menu - Roasting...
- Page 14 OPERATION and no temperature is displayed. Turn on the oven and set the time. rect time. You will be prompted to set the time. Use the sensors to set the correct time. Touch are inactive). nothing for 10 seconds. When you activate the appliance from the standby mode you will hear an acoustic all set functions, automatic programmes, into standby mode you will hear an acoustic...
- Page 15 OPERATION Kitchen Timer The oven continues to use the previous set- The Kitchen Timer counts the time down. After the countdown, you will hear an acoustic signal. The Kitchen Timer runs independently oven resumes the previous mode). Activating of other functions. Using the Kitchen Timer the core temperature sensor does not change the oven temperature settings.
- Page 16 OPERATION You can deactivate the timer by setting the on the display, however, if you touch any sen- duration to 0:00. sor when Child Lock is enabled, both displays will show a key symbol for few seconds. an acoustic signal. All heating elements are disconnected.
- Page 17 OPERATION Heating functions: appliances with a pyrolytic function, and is optional on other appliances. There is a row of 12 touch sensors witch indi- Cooling fan operation cator lights below the displays and the control touch sensors. Extreme sensors control the cleaning and light.
- Page 18 OPERATION Light Fan assisted heating This sensor operates independently Use this function to heat up the oven by a heating element with air functions and settings. circulation forced by a rotating fan wall of the chamber. Lower baking Fast oven heat-up temperatures than in the conventio- Top heater, roaster and fan on.
-
Page 19: Baking In The Oven - Practical Hints
BAKING IN THE OVEN – PRACTICAL HINTS Baking we recommend using the baking trays which were provided with your cooker; it is also possible to bake in cake tins and trays bought elsewhere which should be put on the drying rack; for baking it is better to use black trays which conduct heat better and shorten the baking time;... - Page 20 BAKING IN THE OVEN – PRACTICAL HINTS Oven with automatic air circulation (including a fan and an ultra-fan heater) Type Oven Temperature Level Time in minutes functions dish 160 - 200 2 - 3 160 - 180 20 - 40* 140 - 160 10 - 40* 200 - 230...
-
Page 21: Cleaning And Maintenance
CLEANING AND MAINTENANCE By ensuring proper cleaning and mainte- Replacing the halogen bulb in the oven nance of your cooker you can have a sig- Before replacing the halogen bulb, make operation of your appliance. sure the appliance is disconnected from the electric mains to avoid a possible Before you start cleaning, the cooker must electric shock. - Page 22 CLEANING AND MAINTENANCE Dismounting the side racks runners attached to the wire shelf sup- ports The telescopic runners should be shelf supports. To remove them for washing, removed and cleaned together with the wire shelf supports. Before you put the the support and remove from the rear catch baking tray on them, they should be them in support holes in the oven and press...
- Page 23 CLEANING AND MAINTENANCE Door removal Removing the inner panel chamber for cleaning, it is possible to remove per door slat, prying it gently on the sides the door. To do this, tilt the safety catch part the hinge is correctly placed on the protrusion the oven, the safety catch should be carefully set it may cause damage to the hinge when closing the door.
- Page 24 CLEANING AND MAINTENANCE 3. Pull the inner glass panel from its seat Regular inspections Besides keeping the oven clean, you should: 4. Clean the panel with warm water with some cleaning agent added. trol elements and cooking units of the Carry out the same in reverse order to cooker.
- Page 25 OPERATION IN CASE OF EMERGENCY disconnect the power supply have the appliance repaired Based on the instructions given in the table below, some minor issues can be corrected by the user. Please check the consecutive points in the table before you refer the repair to customer service.
- Page 26 SPECIFICATION Rated voltage The Manufacturer hereby declares that this product complies with the general requirements pursuant to the following European Directives: The Low Voltage Directive Electromagnetic Compatibility Directive 2004/108/EC, ErP Directive 2009/125/EC, and therefore the product has been marked with the symbol and the has been issued to the manufacturer and is available to the competent authorities regulating the market.
