5. Data Report

The device will immediately send a version packet report along with two uplink packets including temperature, battery voltage,
tilt angle of the X, Y, and Z axes.
The device sends data in the default configuration before any configuration is done.
Default Setting:
MaxTime: Max Interval = 60 min = 3600s
MinTime: Max Interval = 60 min = 3600s
BatteryChange = 0x01 (0.1v)
AngleChange = 0x05 (5°)
ActiveThreshold = 0x0003
Deactivetime = 0x05 (5 seconds)
TemperatureChange = 0x0A (1°)
R718EA Reporting Requirements:
When R718EA detects one of the three-axis tilt, and the change amount of angle is equal/greater than the set AngleChange, it
would report at MinTime. R718EA would also report at MinTime while detects the surface temperature changes.
The data of three-axis accelerometer of the device needs to be lower than InActiveThreshold (cannot be modified) and the
duration has to be more than 5 seconds before the next detection. If tilt or vibration continues to occur during this process, it
would restart the timer.
Note:
(1) R718EA is using three-axis accelerometer to detect tilt.
(2) The device report interval will be programmed based on the default firmware which may vary.
(3) The interval between two reports must be the minimum time.
Please refer Netvox LoRaWAN Application Command document and Netvox Lora Command Resolver
http://www.netvox.com.cn:8888/page/index
Data report configuration and sending period are as following:
Min Interval
(Unit:second)
Any number between
1~65535
(Range:0x0003-0x00FF)
(Range:0x0003-0x00FF)
to resolve uplink data.
Max Interval
(Unit:second)
Any number between
1~65535
Reportable Change
Can not be 0.
7
Current Change≥
Reportable Change
Report
per Min Interval
Current Change＜
Reportable Change
Report
per Max Interval
