netvox R718AD User Manual

Wireless temperature sensor
Hide thumbs Also See for R718AD:
1
2
3
4
5
6
Table of Contents

Advertisement

Quick Links

Download this manual
R718AD
Mod：
Wireless Temperature Sensor
Wireless Temperature Sensor
R718AD
User Manual
Version History
Date
Description
Version
2019-9-6
Create Document
V0.1
2019-9-27
Add device appearance
v0.2
Table of Content
1. Introduction.............................................................................................................................................................................................................................................................. 1
2. Appearance............................................................................................................................................................................................................................................................... 1
3. Main Features...........................................................................................................................................................................................................................................................1
4. Set up Instruction..................................................................................................................................................................................................................................................... 2
5. Data Report.............................................................................................................................................................................................................................................................. 3
6. Command Configuration Setting............................................................................................................................................................................................................................. 3
7. Installation................................................................................................................................................................................................................................................................5
8. Important Maintenance Instruction..........................................................................................................................................................................................................................5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R718AD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for netvox R718AD

Summary of Contents for netvox R718AD

  • Page 1: Table Of Contents

    R718AD Mod： Wireless Temperature Sensor Wireless Temperature Sensor R718AD User Manual Version History Date Description Version 2019-9-6 Create Document V0.1 2019-9-27 Add device appearance v0.2 Table of Content 1. Introduction....................................................1 2. Appearance....................................................1 3. Main Features...................................................1 4. Set up Instruction..................................................2 5.

  • Page 2: Introduction

    Introduction R718AD, mainly used to detect the temperature. It collects data over LoRa network and sends it to devices to be shown, fully compatible with LoRa protocol. LoRa Wireless Technology: LoRa is a wireless communication technology dedicated to long distance and low power consumption. Compared with other communication methods, LoRa spread spectrum modulation method greatly increases to expand the communication distance.

  • Page 3: Set Up Instruction

    4. Set up Instruction On/Off Insert batteries. Power on (users may need a flat blade screwdriver to open) Turn on Press and hold the function key for 3 seconds till the green indicator flashes once. Turn off Press and hold the function key for 5 seconds till green indicator flashes for 20 times. (Restore to factory setting) Power off Remove Batteries.

  • Page 4: Data Report

    R718AD default Max Interval = 15min, Min Interval = 15min (if there is special custom shipment, the setting will be changed according to customer requirements) The data reported by the device can be decoded with the Netvox LoraWAN Application Command document and http://www.netvox.com.cn:8888/page/index...
  • Page 5 （1）Command Configuration Setting: （2） MinTime = 1min、MaxTime = 1min、BatteryChange = 0.1v、TemperatureChange = 1℃ Downlink： 019C003C003C0100640000 Response： （Configuration success） 819C000000000000000000 （Configuration failure） 819C010000000000000000 （3）Read Configuration Setting: Downlink： 029C000000000000000000 Response： （Current configuration setting） 829C003C003C0100640000 The data transmission cycle example Example#1 based on MinTime = 1 Hour, MaxTime= 1 Hour, Reportable Change i.e. BatteryVoltageChange=0.1V MaxTime MaxTime leeping(MinTime)

  • Page 6: Installation

    Notes: 1) The device only wakes up and performs data sampling according to MinTime Interval. When it is sleeping, it does not collect data. 2) The data collected is compared with the last data reported. If the data change value is greater than the ReportableChange value, the device reports according to MinTime interval.
