Device elements

Device Information

Indicator elements

6 | © Danfoss | October 2020
This chapter gives an overview of the device elements, functions and describes the intended use. It
further lists the available device variants and the product certifications.
The device elements for the CS100
1
2
1. Mounting holes
2. Housing
3. Status LED
4. Type label
5. 8 Pin DEUTSCH connector
C
Caution
This device is not field serviceable. Opening the housing will void the warranty.
The device is equipped with the indicator element: 1x Device State multicolor LED.
3
4
5
