Technical Information
PLUS+1 Connect CS100 IoT Gateway — Professional Install Only

Device Functions

Available variants & functions

Operating modes

GNSS (Global Navigation Satellite System)

Wireless Solution

SIM card

Input/output functions (I/O)

14 | © Danfoss | October 2020
Variant GNSS
CS100 Yes
CS100 devices operate in Data Logging mode.
Data logging
In this operation mode the CS100 unit logs specific CAN messages, GNSS position data and internal
variables according to its configuration and sends them to the Danfoss PLUS+1® Connect portal.
CS100 devices have an internal non-volatile memory which allow CS100 to store the logged data in case
of a cellular outage. When the cellular connection is recovered the logged data are sent to the Danfoss
PLUS+1® Connect portal automatically.
The GNSS enables the devices to determine their position using the Global Positioning System (GPS). The
position data can then be transmitted via the cellular connection to the Danfoss PLUS+1
or make it available to the connected CAN bus system. The device includes a GNSS receiver for
determining position data: the receiver can process signals from GPS, GLONASS, and BeiDou satellites. It
can process data from multiple navigation systems simultaneously: this increases the accuracy.
The CS100 uses GNSS as a time source. When GNSS sync is not available, the local timing accuracy is ±2
seconds per day.
CS100 interfaces transmit data available on a CAN bus via LTE Cat.M1 and 2G telecommunication
services.
Beyond the LTE Cat.M1/GSM functionality, these services allow for communication with web servers at
higher data rates. The communication is based on the TCP/IP protocol, the communication is encrypted
and secure (TLS). Using these services requires a connection to a Danfoss PLUS+1 Connect portal.
Factory installed into the device there is a network operator SIM card.
Inserting generic SIM card is not possible because the housing cannot be opened.
The functionality depending on the ambient temperature can be assured for the maximum transfer rate
only between -38 °C to 55 °C (36.4 °F to 131 °F).
CS100 feature two multifunction input/output (2 DIN/AIN/ResIN/FreqIN/CrntIN/DOut) configurable with
several options like the same type of pins available on PLUS+1 ECUs. You can use the input function, for
instance, to read and log status information from devices or machines as well as to directly determine
and monitor switch and key states. You can send the data from the input/output function via the CAN
bus or via the mobile radio network.
CAN Bus Local MFIO
Interface
2 2
RTC Data Logging Power
Yes Yes
®
Connect portal
BC299456869228en-000101
Management
Yes
