PLUS+1 Connect CS100 IoT Gateway — Professional Install Only
CS100 Technical Data

Multifunction inputs

18 | © Danfoss | October 2020
Middle range analog
Description
Minimum discernible voltage
Maximum discernible voltage
Resolution
Worst case offset and gain error
Non-linearity
Input impedance
Input impedance (5V/GND)
Input impedance (2.5V)
High range analog
Description
Minimum discernible voltage
Maximum discernible voltage
Resolution
Worst case offset and gain error
Non-linearity
Input impedance
Input impedance (5V/GND)
Input impedance (2.5V)
Frequency input middle range
Description
Range
Range (phase and quad)
Rising voltage threshold
Falling voltage threshold
Input impedance
Input impedance (5V/GND)
Input impedance (2.5V)
Frequency (PPU) High Range
Description
Range
Range (phase and quad)
Rising voltage threshold
Falling voltage threshold
Input impedance
Input impedance (5V/GND)
Input impedance (2.5V)
Unit Minimum Typical
mV — —
V 5.18 5.26
mV — 1.3
mV — —
mV — —
kΩ 232 233
kΩ 13.9 14.1
kΩ 7.1 7.3
Unit Minimum Typical Maximum Comment
mV — —
V 34.5 35.3
mV — 8.6
V — —
mV — —
kΩ 109.1 109.3
kΩ 13.0 13.2
kΩ 6.9 7.0
Unit Minimum Typical Maximum
Hz 0 — 10000
Hz 0 — 5000
V — — 3.89
V 0.85 — —
kΩ 232 233 234
kΩ 13.9 14.1 14.3
kΩ 7.1 7.3 7.4
Unit Minimum Typical Maximum
Hz 0 — 10000
Hz 0 — 5000
V — — 23.6
V 5.6 — —
kΩ 109.1 109.3 109.5
kΩ 13 13.2 13.4
kΩ 6.9 7.0 7.1
Maximum Comment
20 —
5.33 —
— —
71 VMeasure = 5.26 V
±7.8 —
234 No pull up or pull down
14.3 Pull up or pull down
7.4 Pull up and pull down
145 —
36.1 —
— —
.79 VMeasure = 35.5 V
±53 —
109.5 No pull up or pull down (Vin < 5.7 V)
13.4 Pull up or pull down (Vin < 5.7 V)
7.1 Pull up and pull down (Vin < 5.7 V)
Comment
In steps of 1 Hz
In steps of 1 Hz
Voltage required for frequency input
Voltage required for frequency input
No pull up or pull down
Pull up or pull down
Pull up and pull down
Comment
In steps of 1 Hz
In steps of 1 Hz
Voltage required for frequency input
Voltage required for frequency input
No pull up or pull down
Pull up or pull down
Pull up and pull down
