Figure 4: Cross-over cable
1
White/Orange
2
3
White-Green
4
5
White/Blue
6
7
White/Brown
8
Please make sure your connected cables have the same pin assignment
and color as above before deploying the cables in your network.
Installation Guide
Orange
Blue
Green
Brown
White/Orange
Orange
White-Green
Blue
White/Blue
Green
White/Brown
Brown
1
2
3
4
5
6
7
8
17
