Summary of Contents for Interlogix TVB-6101
- Page 1 TruVision HD-TVI Cameras Configuration Manual P/N 1073682-EN • REV A • ISS 06JAN20...
- Page 2 Copyright © 2020 United Technologies Corporation. Interlogix is part of UTC Climate, Controls & Security, a unit of United Technologies Corporation. All rights reserved. Trademarks and Trade names used in this document may be trademarks or registered patents trademarks of the manufacturers or vendors of the respective products.
-
Page 3: Table Of Contents
Content Important information 2 Limitation of liability 2 Advisory messages 2 Introduction 3 Camera and recorder/encoder compatibility 4 Call up the camera OSD menu 5 Menu trees 6 Configure the cameras 8 Video Format 8 Exposure 9 Day/Night 9 Video Settings 11 Smart Light 12 Functions 13 Factory Default 13... -
Page 4: Important Information
Important information Limitation of liability To the maximum extent permitted by applicable law, in no event will UTCFS be liable for any lost profits or business opportunities, loss of use, business interruption, loss of data, or any other indirect, special, incidental, or consequential damages under any theory of liability, whether based in contract, tort, negligence, product liability, or otherwise. -
Page 5: Introduction
Introduction This is the configuration manual for following camera models: HD-TVI 720P Cameras • TVB-6101 (720P Bullet, 2.7 to 13.5 mm lens) • TVD-6101 (720P Dome, 2.7 to 13.5 mm lens) HD-TVI 2MPx Cameras • TVB-6102 (2MPx Bullet, 3.6 mm lens) •... -
Page 6: Camera And Recorder/Encoder Compatibility
Camera and recorder/encoder compatibility Table 1 below shows the compatibility of the cameras with TruVision recorders and encoders. Table 1: Camera compatibility with TruVision recorders and encoders TVR 12HD TVR 44HD TVR 15HD TVR 45HD V1.2.j V1.2.j V2.0.e V2.1.b Live Live Live Record... -
Page 7: Call Up The Camera Osd Menu
Call up the camera OSD menu You can configure the camera settings via a TVI DVR. Select the PTZ protocol TruVision Coax and click the menu button to call up the menu. The TVS-C200 controller (Service Tool) does not support these TVI cameras. When using the TVI output, the TVI cameras must be used with TVI DVRs. -
Page 8: Menu Trees
Menu trees 720P and 2MPx cameras: 5MPx and 8MPx cameras: VIDEO VIDEO FORMAT FORMAT EXPOSURE MODE EXPOSURE MODE SLOW SHUTTER BACK EXPOSURE BACK EXPOSURE EXIT EXIT SAVE & EXIT SAVE & EXIT MODE MODE IR LIGHT DAY/NIGHT SMART IR BACK DAY/NIGHT LEVEL EXIT... - Page 9 Full time color cameras: FORMAT EXPOSURE MODE EXPOSURE SLOW SHUTTER BACK EXIT SAVE & EXIT IMAGE MODE WHITE BALANCE BRIGHTNESS CONTRAST VIDEO SETTINGS SHARPNESS SATURATION 3 DNR MIRROR MAIN MENU BACK EXIT SAVE & EXIT LIGHT SMART THRESHOLD LIGHT LEVEL MODE BACK EXIT...
-
Page 10: Configure The Cameras
Configure the cameras This section describes how to set up the menu settings for the TruVision HD-TVI cameras. Video Format Move the cursor to FORMAT and select the desired video format. • HD-TVI 720P cameras: 720P@25 fps or 720P@30 fps •... -
Page 11: Exposure
Exposure Move the cursor to EXPOSURE and click Iris+ to enter the submenu. This defines the brightness-related parameters. Adjust the image brightness using EXPOSURE MODE, SLOW SHUTTER for different lighting conditions. The function SLOW SHUTTER is not available for all camera models. EXPOSURE GLOBAL EXPOSURE MODE... - Page 12 MODE You can select one of three options to control Day/Night mode: COLOR, BW (Black White), or AUTO. COLOR: The image is colored in day mode all the time. B & W: The image is black and white all the time. The IR LEDs turn on in poor lighting conditions.
-
Page 13: Video Settings
Nà D Threshold Night to Day Threshold is used to control the sensitivity of switching from night mode to day mode. You can set the value from 1 to 9. The larger the value, the more sensitive the camera is to switching from night mode to day mode. -
Page 14: Smart Light
SHARPNESS This function increases the image gain and sharpens the edges in the image to enhance image details. You can set the value from 1 to 9. The higher the value, the stronger the effect. Default is SATURATION Saturation indicates the brightness of the color. The higher the saturation, the brighter the color. The value ranges from 1 to 9. -
Page 15: Functions
MODE There are two mode levels, 1 and 2. Mode 1 has a warmer white light than mode 2. Functions Move the cursor to FUNCTIONS and click Iris+ to enter the submenu. This menu defines motion detection and privacy. MOTION DETECTION In the user-defined motion detection surveillance area, the moving object can be detected and the alarm will be triggered. -
Page 16: Save & Exit
Save & Exit Move the cursor to SAVE & EXIT and click Iris+ to save the settings, and exit the menu. TruVision HD-TVI Cameras Configuration Manual...
